SECO-LARM SD-9163-KSVQ – Outdoor Wave-to-Open Sensor with Manual Override (Slimline)
Weatherproof, touchless IR exit sensor with stainless steel plate and adjustable LED feedback for hygienic access control applications.
The SD-9163-KSVQ is a slim, outdoor-rated wave-to-open sensor designed for no-touch egress or activation. Featuring adjustable detection range, a selectable LED color change (red to green or vice versa), and a built-in manual override button, this sensor is ideal for use in hospitals, cleanrooms, schools, and industrial environments. The stainless steel faceplate and IP65 rating ensure long-term durability in demanding locations.
Key Features:
• Activation Type: IR wave sensor with manual override
• Range: Adjustable 2″–7″ (5–18 cm)
• Output: SPDT dry contact relay, 1.2A@24VDC
• Trigger Duration: Adjustable 0.5–30 seconds or toggle
• LED Indicators: Red/Green (color change selectable)
• Power: 12–24VDC
• Current Draw: Max 28mA triggered, 12–15mA standby
• IP Rating: IP65 weather-resistant
• Construction: Stainless steel plate with sealed sensor
• Dimensions: 1-1/2″ x 4-1/2″ (39 x 115 mm)
Ideal For:
• Hospitals, clinics, and cleanrooms
• Warehouses, schools, and labs
• Outdoor egress and hands-free door activation
Why You Should Use This:
• Provides touch-free activation for hygienic access control
• Slim design fits tight door frame or post-mount applications
• Adjustable range and timing make it versatile for any setting
Key Highlights:
- ✅ Hands-free IR sensor with adjustable range up to 7″
- ✅ IP65-rated stainless steel faceplate for outdoor use
- ✅ Manual override push button built in
- ✅ LED feedback with color change when activated
Frequently Asked Questions:
Q: Can the sensor be used outdoors?
A: Yes, the SD-9163-KSVQ is IP65 rated and designed for outdoor installation.
Q: Does this include a manual push button override?
A: Yes, a built-in button is available for backup manual activation.
Q: Can the LED color direction be changed?
A: Yes, you can choose whether it changes from red to green or green to red on activation.
