APC NetShelter Switched Rack PDU, 2G, 0U, 30A, 100V to 120V, 24 NEMA 5-20R outlets - AP8932

APC NetShelter Switched Rack PDU, 2G, 0U, 30A, 100V to 120V, 24 NEMA 5-20R outlets - AP8932

SKU: AP8932

Regular price $1,759.99 USD
Regular price Sale price $1,759.99 USD
Sale Sold out

 5 in stock

View full details

APC NetShelter Switched Rack PDU, 2G, 0U, 30A, 100V to 120V, 24 NEMA 5-20R outlets - AP8932

Key Features

  • 2 year warranty & Green PremiumTM label (see specifications)
  • Ideal for remote monitoring, reboots, powerup sequencing, scheduling power loads
  • Power sequencing delays determine the order in which power is turned on or off
  • Remote management of rack PDUs for efficient time-saving
  • User-defined alarms warn of potential circuit overloads before critical IT failures occur
  • Zero U toolless installation

Product Overview

APC Switched Rack Power Distribution Units (PDUs) enable advanced, user-customizable power control and active monitoring Remote outlet level controls allow power on/off functionality for power recycling to remotely reboot equipment and restrict unauthorized use of individual outlets Power sequencing delays allow users to define the order in which to power up or down attached equipment Avoid circuit overload during power recovery and extend uptime of critical equipment by prioritizing the load shedding Current metering provides real-time remote monitoring of connected loads Switched Rack PDUs include real power monitoring, a temperature/humidity sensor port, locking IEC receptacles, and low profile circuit breakers User-defined alarms warn of potential circuit overloads before critical IT failures occur Users can access, configure, and control Switched Rack PDUs through secure Web, SNMP, or Telnet Interfaces and is complimented by APC Centralized Management platforms using InfraStruxure Central, Capacity Manager and Change Manager

General Information

  • Manufacturer: Schneider Electric SA
  • Manufacturer Part Number: AP8932
  • Brand Name: APC by Schneider Electric
  • Product Name: Rack PDU 2G, Switched, ZeroU, 30A, 100-120V, (24) 5-20R
  • Packaged Quantity: 1 Each
  • Product Type: PDU

Technical Information

  • PDU Type: Switched
  • Plug/Connector Type: NEMA L5-30P
  • Receptacle Type: NEMA 5-20R
  • Receptacle Detail: 24 x NEMA 5-20R
  • Protection Type: Overload Protection

Power Description

  • Input Voltage:
    • 100 V
    • 120 V

  • Output Voltage:
    • 100 V AC
    • 120 V AC

  • Power Rating (VA): 2880 VA
  • Input Current: 30 A

Management

  • Management:
    • Web
    • SNMP
    • Telnet

Physical Characteristics

  • Color Family: Black
  • Product Color: Black
  • Mounting Orientation: Vertical
  • Mount Type: Rack-mountable
  • Form Factor: Tower
  • Placement: Side
  • Rack Height: 0U
  • Cord Length: 9.51 ft
  • Height: 70.5"
  • Width: 2.2"
  • Depth: 1.8"
  • Weight (Approximate): 17.31 lb

Miscellaneous

  • Package Contents:
  • Rack PDU 2G, Switched, ZeroU, 30A, 100-120V, (24) 5-20R
  • Installation guide
  • Rack mounting brackets
  • Safety guide
  • Serial configuration cable

  • Country of Origin: India
  • Environmentally Friendly: Yes
  • Environmental Compliance: Restriction of Hazardous Substances (RoHS)

Warranty

  • Limited Warranty: 2 Year
