Eaton Tripp Lite Series 750VA 450W Standby UPS - 12 NEMA 5-15R Outlets, 120V, 50/60 Hz, 5-15P Plug, ENERGY STAR, Desktop/Wall - ECO750UPS
Key Features
- $100,000 Ultimate Lifetime Insurance
- 12 NEMA 5-15R outlets power and protect PC, home theater or digital signage equipment
- 3-year limited warranty
- ENERGY STAR-certified to save electricity, lower costs, and protect the environment
- Home-friendly alarm remains silent in backup mode, sounding only when imperative
- Keeps AC power running during blackouts to allow time for file saves and safe shutdown
- Protects equipment against blackouts, brownouts, overvoltages, surges and line noise
Product Overview
Ultra-high efficiency ECO Series UPS System saves energy by automatically powering off unused computer accessories when the computer is not in use. UPS system uses less electricity than conventional models. Design includes six battery-supported outlets for computer, monitor and four vital system peripherals, plus six additional surge suppression-only outlets for accessories not requiring battery support. Four of the surge-only outlets are designated Eco outlets that can be configured to automatically power off when the computer enters standby mode or is shutdown. USB port enables UPS configuration options and unattended system shutdown without data loss in the case of extended power failure. Built-in, single-line RJ11 phone suppression protects modem, fax machine, cordless phone or other accessories with a dialup/DSL phone connection. UPS system meets RoHS standards. 750VA/450-watt power handling ability supports entry-level PC systems for up to 45 minutes during power fail conditions.General Information
- Manufacturer: Eaton Corporation
- Manufacturer Part Number: ECO750UPS
- Brand Name: Tripp Lite series
- Product Series: ECO
- Product Name: ECO 750VA Desktop UPS
- Packaged Quantity: 1 Each
- Product Type: Standby UPS
Technical Information
- Plug/Connector Type: NEMA 5-15P
- Receptacle Type: NEMA 5-15R
- Receptacle Detail: 12 x NEMA 5-15R
- Number of Battery & Surge Outlets: 6
- Number of Surge-only Outlets: 6
- Dataline Protection:
- RJ-11
- RJ-45
- Transfer Time: 6 ms
- EMI/RFI Noise Filter: Yes
- Phase: Single Phase
- Energy Saving: Greater than 95% efficiency - GREEN UPS; Power saving auto-shutoff ECO outlets
- Application/Usage:
- Kiosk
- Security System
- Business
- Computer
- Router
- Printer
- TV
- Blu-ray Player
- Gaming Console
- ATM
- Digital Signage
Power Description
- Load Capacity (VA): 750 VA
- Load Capacity (Watt): 450 W
- Input Voltage: 120 V AC
- Output Voltage:
- 110 V AC
- 115 V AC
- 120 V AC
- Input Frequency: 60 Hz
- Output Frequency: 60 Hz
- Waveform Type: Pure Sine Wave
- Surge Energy Rating: 316 J
Management
- Alarm:
- Low Battery
- Fault
- Overload
- Replace Battery
Controls/Indicators
- Status Indicators:
3 Status LEDs; GREEN #1 LED reports ECO mode off/on status; GREEN #2 LED reports line/battery mode operation, low-battery condition, overload and replace-battery notifications; RED LED reports battery-low, overload, replace-battery and fault conditions
Interfaces/Ports
- USB: Yes
- USB (HID Compliant) Port: Yes
Battery Information
- DC System Voltage: 12 V DC
- Backup/Run Time (Full Load): 2 Minute
- Backup/Run Time (Half Load): 8.60 Minute
- Typical Battery Recharge Time: 6.50 Hour
- Replaceable Battery: Yes
Environmental Conditions
- Maximum Operating Elevation: 10000 ft
- Storage Temperature: 5°F (-15°C) - 113°F (45°C)
- Maximum Operating Temperature: 104°F (40°C)
Physical Characteristics
- Height: 3.4"
- Width: 5.1"
- Depth: 12.2"
- Form Factor: Ultra-compact Desktop/Tower/Wall Mount
- Weight (Approximate): 6.82 lb
Miscellaneous
- Package Contents:
- ECO 750VA Desktop UPS
- Owner's Manual
- USB Cable
- Energy Star: Yes
- Country of Origin: China
- Environmental Compliance: Restriction of Hazardous Substances (RoHS)
Warranty
- Limited Warranty: 3 Year
- Additional Warranty Information:
2 year
- 100,000 connected equipment guarantee
