Camera
Image Sensor: 1/3" Progressive Scan CMOS
Max. Resolution: 2688 × 1520
Min. Illumination: Color: 0.001 Lux @ (F1.0, AGC ON), 0 Lux with Light
Shutter Time: 1/3 s to 1/100,000 s
Day & Night: IR Cut Filter
Angle Adjustment: Pan: 0° to 360°, Tilt: 0° to 75°, Rotate: 0° to 360°
Lens
Type: Fixed focal lens, 2.8 mm and 4 mm optional
FOV:
2.8 mm: Horizontal 100.2°, Vertical 54.7°, Diagonal 119.7°
4 mm: Horizontal 81.1°, Vertical 44.7°, Diagonal 94.6°
Lens Mount: M12
Aperture: F1.0
Depth of Field:
2.8 mm: 1.9 m to ∞
4 mm: 2.5 m to ∞
DORI
2.8 mm: D: 63 m, O: 25 m, R: 12 m, I: 6 m
4 mm: D: 78 m, O: 31 m, R: 15 m, I: 7 m
Illuminator
Supplement Light: IR, White Light
Range: Up to 40 m
Smart Supplement Light: Yes
IR Wavelength: 850 nm
HEOP (Hikvision Embedded Open Platform)
Memory: 60 MB, Smart RAM: 400 MB, eMMC: 2 GB
Computing Power: 1.5 TOPS
SDK: HEOP 2.0 OpendevSDK
Supported Frameworks: Caffe, PyTorch, TensorFlow, PaddlePaddle, ONNX
Programming Languages: C, C++
Video
Main Stream: 2688 × 1520, 1920 × 1080, 1280 × 720 (25/30 fps)
Sub-Stream: 1280 × 720, 640 × 480, 640 × 360 (25/30 fps)
Third Stream: Up to 1920 × 1080 @ 10 fps
Fourth Stream: Up to 1280 × 720 @ 10 fps
Compression: H.265+/H.265/H.264+/H.264/MJPEG
Bit Rate: 32 Kbps to 8 Mbps
ROI: 5 fixed regions (Main & Sub-stream)
Target Cropping: Yes
Audio
Compression: G.711, G.722.1, G.726, MP2L2, PCM, MP3, AAC-LC
Bit Rate: 64–320 Kbps depending on format
Sampling Rate: 8–48 kHz
Noise Filtering: Yes
Network
Protocols: TCP/IP, HTTPS, FTP, RTP/RTSP, NTP, SMTP, IGMP, QoS, IPv4/IPv6, SNMP, SFTP, SRTP, and more
Live View: Up to 6 channels
API: ONVIF (S, G, T), ISAPI, SDK, ISUP
Users: Up to 32 (Admin, Operator, User)
Security: HTTPS, 802.1X, TLS 1.1/1.2/1.3, Watermark, MAC Filtering, WSSE
Storage
Network: NAS (NFS/SMB), ANR
Local: microSD/microSDHC/microSDXC up to 512 GB
Settings: Rotate, Saturation, Brightness, Contrast, Sharpness, Gain, White Balance
WDR: 120 dB
SNR: ≥ 52 dB
Enhancements: BLC, HLC, 3D DNR
Privacy Masks: 4 polygon masks
Interfaces
Ethernet: 1 × RJ45 10/100 Mbps
Audio I/O: 1 in / 1 out (3.3 Vpp, terminal block)
Alarm I/O: 1 input / 1 output (max. 12 VDC, 30 mA)
Reset Button: Yes
Power Output: 12 VDC, max. 100 mA
Smart Features
Events: Motion Detection, Tampering, Exception, Audio Exception, Scene Change
Smart Detection: Line Crossing, Intrusion, Region Entrance/Exit
AI Features: Face Capture, People Counting
General
Power: 12 VDC ± 25% (0.66 A, max. 8 W), PoE (802.3af, max. 10 W)
Material: Metal Housing
Dimensions: Ø127.3 × 96.3 mm (Ø5" × 3.8")
Weight: 550 g (1.2 lb); With package: 800 g (1.8 lb)
Storage Temp: –30 °C to 60 °C (–22 °F to 140 °F)
Operating Temp: –30 °C to 60 °C (–22 °F to 140 °F)
Humidity: ≤ 95% (non-condensing)
Certifications
EMC: FCC, CE-EMC, RCM, IC
Safety: UL, CB, CE-LVD, BIS, LOA
Environment: RoHS, WEEE, REACH
Protection: IP67
Supported Languages: English, Spanish, French, German, Russian, Portuguese (Brazil), Chinese, Japanese, Turkish, and 25+ others
