Video Encoding
H.264 Type: Baseline Profile / Main Profile / High Profile
H.265 Type: Main Profile
Bit Rate Control: CBR / VBR
Scalable Video Coding (SVC): H.264 and H.265 encoding
Region of Interest (ROI): 1 fixed region for main and sub-stream
Audio
Environment Noise Filtering: Yes
Audio Sampling Rate: 8 kHz / 16 kHz / 32 kHz / 44.1 kHz / 48 kHz
Audio Compression: G.711ulaw / G.711alaw / G.722.1 / G.726 / MP2L2 / PCM / MP3 / AAC
Audio Bit Rate: 64 Kbps (G.711ulaw/alaw), 16 Kbps (G.722.1/G.726),
32–192 Kbps (MP2L2), 8–320 Kbps (MP3), 16–64 Kbps (AAC)
Network
Simultaneous Live View: Up to 6 channels
API: ONVIF (Profile S, G, T), ISAPI, SDK, ISUP
Protocols: TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4/IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP
User/Host: Up to 32 users (Admin, Operator, User)
Security: HTTPS encryption, IP filtering, security audit log, password protection, TLS 1.1/1.2, WSSE, HTTP/HTTPS digest authentication
Network Storage: NAS (NFS, SMB/CIFS), Auto Network Replenishment (ANR)
Client: iVMS-4200, Hik-Connect, Hik-Central
Web Browser:
Plug-in required: IE10/11
Plug-in free: Chrome 57+, Firefox 52+
Local service: Chrome 57+, Firefox 52+
Wide Dynamic Range (WDR): 130 dB
Privacy Mask: 8 programmable polygons (color/mosaic configurable)
Day/Night Switch: Day, Night, Auto, Schedule
Image Enhancement: BLC, HLC, 3D DNR
Image Settings: Rotate mode, saturation, brightness, contrast, sharpness, gain, white balance – adjustable via software or browser
Interface
Ethernet Interface: (1) RJ45 10M/100M self-adaptive Ethernet port
On-Board Storage: MicroSD/SDHC/SDXC/TF card, up to 256 GB
Built-in Microphone: Yes (LU model)
Event
Basic Events: Motion detection (human/vehicle target), video tampering, network disconnect, IP conflict, illegal login, HDD full/error
Smart Events: Line crossing, intrusion, region entrance/exit, scene change detection
Linkage Actions: Upload to NAS/memory card/FTP, notify surveillance center, trigger record/capture, send email
Deep Learning Function: Face Capture: Yes
Power
-L Model: 12V DC, 0.42A (Max 5W), PoE: 802.3af (36V–57V), 0.17–0.11A, Max 6W
-LU Model: 12V DC, 0.46A (Max 5.5W), PoE: 802.3af (36V–57V), 0.18–0.11A, Max 6.5W
Construction
Material: Cover: Metal, Body: Metal
Dimensions: Ø138.3 mm × 120.1 mm (Ø5.4" × 4.7")
Package Dimensions: 170 × 170 × 150 mm (6.7" × 6.7" × 5.9")
Weight: Approx. 870 g (1.9 lb)
With Package: Approx. 1160 g (2.6 lb)
Environmental Conditions
Storage: –30°C to 60°C (–22°F to 140°F), 95% RH max (non-condensing)
Startup/Operating: –30°C to 60°C (–22°F to 140°F), 95% RH max (non-condensing)
Language Support: 33 languages including English, Spanish, French, German, Russian, Japanese, Chinese, Korean, Portuguese (Brazil), Turkish, Ukrainian, and more
General Functions: Anti-flicker, heartbeat, mirror, password reset via email, pixel counter
Software Reset: Yes
Certifications
EMC: FCC, CE-EMC, RCM, IC, KC
Safety: UL, CB, CE-LVD
Environment: RoHS, WEEE, REACH
Protection: IP67 (IEC 60529-2013)Camera
Image Sensor: 1/1.2″ Progressive Scan CMOS
Max. Resolution: 3840 × 2160
Minimum Illumination: Color: 0.0005 Lux @ (F1.0, AGC ON)
Shutter Speed: 1/3 s to 1/100,000 s
Day & Night: 24/7 Color Imaging
Angle Adjustment: Pan: 0° to 360°, Tilt: 0° to 75°, Rotate: 0° to 360°
Lens
Lens Type: Fixed focal lens, 2.8 mm and 4 mm optional
Focal Length & Field of View:
2.8 mm – Horizontal FOV: 102°, Vertical FOV: 52°, Diagonal FOV: 124°
4 mm – Horizontal FOV: 88°, Vertical FOV: 47°, Diagonal FOV: 104°
Lens Mount: M16
Iris Type: Fixed
Aperture: F1.0
Depth of Field:
2.8 mm: 3.1 m to ∞
4 mm: 3.6 m to ∞
DORI (Detect, Observe, Recognize, Identify)
2.8 mm: Detect: 96 m, Observe: 38 m, Recognize: 19 m, Identify: 9 m
4 mm: Detect: 102 m, Observe: 40 m, Recognize: 20 m, Identify: 10 m
Illuminator
Supplement Light Type: White Light
Supplement Light Range: Up to 30 m
Smart Supplement Light: Yes
Video
Main Stream:
50 Hz: 25 fps (3840 × 2160, 3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)
60 Hz:
24 fps (3840 × 2160)
30 fps (3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)
Sub-Stream:
50 Hz: 25 fps (640 × 480, 640 × 360)
60 Hz: 30 fps (640 × 480, 640 × 360)
Third Stream:
50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
Video Compression:
Main stream: H.265 / H.264 / H.264+ / H.265+
Sub-stream: H.265 / H.264 / MJPEG
Third stream: H.265 / H.264
Video Bit Rate: 32 Kbps to 16 Mbps
Video Encoding
H.264 Type: Baseline Profile / Main Profile / High Profile
H.265 Type: Main Profile
Bit Rate Control: CBR / VBR
Scalable Video Coding (SVC): H.264 and H.265 encoding
Region of Interest (ROI): 1 fixed region for main and sub-stream
Audio
Environment Noise Filtering: Yes
Audio Sampling Rate: 8 kHz / 16 kHz / 32 kHz / 44.1 kHz / 48 kHz
Audio Compression: G.711ulaw / G.711alaw / G.722.1 / G.726 / MP2L2 / PCM / MP3 / AAC
Audio Bit Rate: 64 Kbps (G.711ulaw/alaw), 16 Kbps (G.722.1/G.726),
32–192 Kbps (MP2L2), 8–320 Kbps (MP3), 16–64 Kbps (AAC)
Network
Simultaneous Live View: Up to 6 channels
API: ONVIF (Profile S, G, T), ISAPI, SDK, ISUP
Protocols: TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4/IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP
User/Host: Up to 32 users (Admin, Operator, User)
Security: HTTPS encryption, IP filtering, security audit log, password protection, TLS 1.1/1.2, WSSE, HTTP/HTTPS digest authentication
Network Storage: NAS (NFS, SMB/CIFS), Auto Network Replenishment (ANR)
Client: iVMS-4200, Hik-Connect, Hik-Central
Web Browser:
Plug-in required: IE10/11
Plug-in free: Chrome 57+, Firefox 52+
Local service: Chrome 57+, Firefox 52+
Wide Dynamic Range (WDR): 130 dB
Privacy Mask: 8 programmable polygons (color/mosaic configurable)
Day/Night Switch: Day, Night, Auto, Schedule
Image Enhancement: BLC, HLC, 3D DNR
Image Settings: Rotate mode, saturation, brightness, contrast, sharpness, gain, white balance – adjustable via software or browser
Interface
Ethernet Interface: (1) RJ45 10M/100M self-adaptive Ethernet port
On-Board Storage: MicroSD/SDHC/SDXC/TF card, up to 256 GB
Built-in Microphone: Yes (LU model)
Event
Basic Events: Motion detection (human/vehicle target), video tampering, network disconnect, IP conflict, illegal login, HDD full/error
Smart Events: Line crossing, intrusion, region entrance/exit, scene change detection
Linkage Actions: Upload to NAS/memory card/FTP, notify surveillance center, trigger record/capture, send email
Deep Learning Function: Face Capture: Yes
Power
-L Model: 12V DC, 0.42A (Max 5W), PoE: 802.3af (36V–57V), 0.17–0.11A, Max 6W
-LU Model: 12V DC, 0.46A (Max 5.5W), PoE: 802.3af (36V–57V), 0.18–0.11A, Max 6.5W
Construction
Material: Cover: Metal, Body: Metal
Dimensions: Ø138.3 mm × 120.1 mm (Ø5.4" × 4.7")
Package Dimensions: 170 × 170 × 150 mm (6.7" × 6.7" × 5.9")
Weight: Approx. 870 g (1.9 lb)
With Package: Approx. 1160 g (2.6 lb)
Environmental Conditions
Storage: –30°C to 60°C (–22°F to 140°F), 95% RH max (non-condensing)
Startup/Operating: –30°C to 60°C (–22°F to 140°F), 95% RH max (non-condensing)
Language Support: 33 languages including English, Spanish, French, German, Russian, Japanese, Chinese, Korean, Portuguese (Brazil), Turkish, Ukrainian, and more
General Functions: Anti-flicker, heartbeat, mirror, password reset via email, pixel counter
Software Reset: Yes
Certifications
EMC: FCC, CE-EMC, RCM, IC, KC
Safety: UL, CB, CE-LVD
Environment: RoHS, WEEE, REACH
Protection: IP67 (IEC 60529-2013)
