Hikvision ColorVu DS-2CD2387G2-LU 8MP IP Turret Camera (Black)
The Hikvision ColorVu DS-2CD2387G2-LU is an 8 MP IP turret camera designed for outdoor surveillance. It provides high quality imaging at 3840 × 2160 resolution and supports efficient H.265+ compression. Wide dynamic range rated at 130 dB helps keep details visible in scenes with strong backlight.
This camera supports human and vehicle target classification based on deep learning and includes a built-in microphone for real-time audio security. It is rated IP67 for water and dust resistance and supports 24/7 colorful imaging. Power over Ethernet (PoE) enables power and data transmission over a single Ethernet cable.
Network storage is supported, and together with high-end Hikvision memory cards, memory card encryption and health detection are supported.
Key Features
8 MP resolution (3840 × 2160)
ColorVu 24/7 colorful imaging
Fixed 2.8mm lens
130 dB wide dynamic range (WDR)
Efficient H.265+ compression technology
Human and vehicle targets classification based on deep learning
Built-in microphone for real-time audio security
IP67 water and dust resistance
PoE support (802.3af)
Memory card encryption and health detection supported with high-end Hikvision memory cards
Video & Imaging
Main stream (50 Hz): 25 fps (3840 × 2160, 3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)
Main stream (60 Hz): 24 fps (3840 × 2160), 30 fps (3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)
Sub-stream (50 Hz): 25 fps (640 × 480, 640 × 360)
Sub-stream (60 Hz): 30 fps
Video bitrate: 32 Kbps to 16 Mbps
Video compression: H.265, H.264, H.265+, H.264+
Scalable video coding (SVC) support
Region of interest support for main stream and sub-stream
Lens & Field of View
Focal length: 2.8mm
Angular field of view: Horizontal 102°, Vertical 52°, Diagonal 124°
Maximum aperture ratio: f/1.0
Depth of field: 3.1 m to infinity
Illumination
Up to 30 m IR white supplement light
Low-light rating: Color - 0.0005 Lux @ (F1.0, AGC On)
Analytics & AI Capabilities
Motion detection
People detection
Vehicle detection
Face detection
Intrusion detection
Virtual line crossing detection
Entering/Exiting detection
Scene change detection
Camera sabotage / tampering
Audio
Built-in microphone
Audio compression: G.711Ulaw, G.711Alaw, G.722.1, G.726, MP2L2, PCM, MP3, AAC
Networking & Security
IPv4 and IPv6 support
Supported protocols include TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, and ONVIF Profiles S, G, and T
Security features include password protection, HTTPS encryption, IP address filtering, security audit logs, and digest authentication
Storage
Built-in memory card slot supporting microSD, microSDHC, and microSDXC cards up to 256GB
Network-attached storage support (NAS with NFS and SMB/CIFS)
Auto network replenishment (ANR)
Power
12 VDC power input (0.46 A)
PoE supported (802.3af)
Power consumption: maximum 5.5 W, PoE maximum 6.5 W
Environmental & Physical
Outdoor rated (IP67)
Operating temperature: -30°C to 60°C (-22°F to 140°F)
Operating humidity: up to 95% (non-condensing)
Material: metal
Camera dimensions: 5.4 × 4.7 in
Camera weight: 1.9 lb
Frequently Asked Questions
Does this camera support 24/7 color imaging?
Yes. This model supports 24/7 colorful imaging.
Does the DS-2CD2387G2-LU include audio?
Yes. The camera includes a built-in microphone for real-time audio security.
Is this camera rated for outdoor use?
Yes. The camera is water and dust resistant with an IP67 rating.
