IP
IPv4, IPv6
Power over Ethernet (PoE)
Yes (802.3af, Class 3)
Camera Body
Turret
Lens
4mm Fixed Focal
Camera Type
Panoramic ColorVu
Audio
Audio Type: Mono Sound
Audio Compression: G.711 / G.722.1 / G.726 / MP2L2 / PCM / MP3 / AAC-LC
Audio Bit Rate: 64 Kbps (G.711 uLaw / aLaw), 16 Kbps (G.722.1), 16 Kbps (G.726), 32–192 Kbps (MP2L2), 8–320 Kbps (MP3), 16–64 Kbps (AAC-LC)
Color
White
Video
Main Stream (WDR On): 50 Hz: 12.5 fps (5120 × 1440), 60 Hz: 15 fps (5120 × 1440)
Main Stream (WDR Off): 50 Hz: 20 fps (5120 × 1440), 60 Hz: 20 fps (5120 × 1440)
Sub-Stream (WDR On): 50 Hz: 12.5 fps (1920 × 536, 960 × 272)
Client Software
iVMS-4200, Hik-Connect, Hik-Central
Series
Pro
Coverage Distance
Detect: 77 m
Observe: 30 m
Recognize: 15 m
Identify: 7 m
Material
Metal
Security
Password Protection, Complicated Password, HTTPS Encryption, 802.1X Authentication (EAP-MD5), Watermark, IP Address Filter, Basic and Digest Authentication for HTTP/HTTPS, TLS 1.1/1.2, WSSE and Digest Authentication for Open Network Video Interface
Analytics
Entering/Exiting, Intrusion Detection, Motion Detection, People Detection, Scene Change Detection, Vehicle Detection, Virtual-Line Crossing Detection
Iris Type
Fixed
Protocols
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, ISUP, ARP, WebSocket, WebSocket'S
Reset Key
Yes
Lens Mount
M16
Ingress Protection
IP67 (IEC 60529-2013)
Resolution
8 MP (5120 × 1440)
Users
Up to 32 users
3 user levels: Administrator, Operator, User
Illuminator
Up to 30 m IR white supplement light
Web Browser Support
Plug-in required: IE 10 / IE 11
Plug-in free: Chrome 57.0+, Firefox 52.0+, Edge 89+
Local service: Chrome 57.0+, Firefox 52.0+, Edge 89+
Face Capture
Supported
Focal Length
4mm
Image Sensor
2 × 1/1.8" Progressive Scan CMOS
Power Supply
12 VDC ±25%, 0.88 A, 5.5 mm dia coaxial power plug
SD Card Slot
Built-in memory card slot
Supports microSD / microSDHC / microSDXC up to 512 GB
Camera Weight
2.4 lb
Day & Night
Color
Shutter Speed
1/30 – 1/100000 sec
Video Bitrate
32 Kbps – 16 Mbps
White Balance
Yes
Certifications
FCC: 47 CFR Part 15, Subpart B
CE-EMC: EN 55032:2015; EN 61000-3-2:2019; EN 61000-3-3:2013+A1:2019; EN 50130-4:2011+A1:2014
RCM: AS/NZS CISPR 32:2015
IC: ICES-003 Issue 7
UL: UL 62368-1
CB: IEC 62368-1:2014+A11
Depth of Field
3.6 m to infinity
Image Settings
Saturation, Brightness, Contrast, Sharpness, AGC, White Balance adjustable by client software or web browser
Installation Environment
Outdoor
AI Capabilities
Basic Event: Motion Detection (supports alarm triggering by specified target types: human and vehicle), alarm input/output, flashing alarm light output, audible alarm output, exception
Smart Event: Scene Change Detection
Network Storage
NAS (NFS, SMB/CIFS), Auto Network Replenishment (ANR), NVR
Angle Adjustment
0–30° pan, -75° to 75° tilt
Bit Rate Control
CBR / VBR
Built-in Speaker
Max power consumption: 1.2 W
Max sound pressure: 95 dB at 10 cm
General Functions
Anti-banding, heartbeat, password reset via email, password protection, one-key reset
Webpage Language
33 languages
Camera Dimensions
6.1 × 6.1 in
Image Enhancement
BLC, HLC, 3D DNR
Power Consumption
Maximum 10.5 W
PoE: Maximum 12.5 W
0.35 A to 0.22 A (36 V to 57 V)
Ethernet Interface
(1) RJ45 10M/100M self-adaptive
Wide Dynamic Range
130 dB
Built-in Microphone
Yes
Day & Night Switch
Day, Night, Auto, Schedule
Night Vision
Color: 0.0005 lux @ (F1.0, AGC on)
B/W: 0 lux with light
Angular Field of View
Horizontal: 180°
Vertical: 44°
Signal-to-Noise Ratio
>52 dB
Maximum Aperture
F1.0
Simultaneous Live View
Up to 6 channels
Video Compression
Main Stream: H.265+ / H.265 / H.264+ / H.264
Sub-Stream: H.265 / H.264 / MJPEG
Image Parameters Switch
Yes
Region of Interest (ROI)
1 fixed region for main stream
Environment Noise Filtering
Supported
Scalable Video Coding (SVC)
H.264 and H.265 encoding
Operating Humidity
95% or less RH (non-condensing)
API
ONVIF (Profile S, Profile G, Profile T), ISAPI, SDK, ISUP
Operating Temperature
-30°C to 60°C (-22°F to 140°F)
