Low-Profile Push to Exit Button with Selectable Normally Open or Normally Closed Momentary Contact, 1A at 12VDC Rating, Concealed Screw Terminals, and Interchangeable Emergency and Exit Labels for Indoor Access Control Installations
The Seco-Larm SS-075C-PEQ is a low-profile push to exit button with a selectable normally open or normally closed momentary contact rated at 1A at 12VDC. The SS-075C-PEQ operates on 12 to 24VDC, features concealed screw terminals for a clean installation appearance, and includes three interchangeable adhesive labels: Emergency, Push to Exit, and Presione Para Salir.
The compact 3 x 15/16 x 5/8 inch off-white housing blends with standard interior decor and fits tight mounting locations where a discreet exit or emergency button is needed. The selectable NO/NC contact configuration adapts to both normally open and normally closed access control panel inputs without requiring a separate button model for each wiring scheme.
Where the SS-075C-PEQ Fits
- Request-to-exit stations at access-controlled doors where the momentary contact sends a brief signal to an access control panel or electric lock to trigger a door release, the low-profile off-white housing blends with interior walls and door frames, and the concealed screw terminals provide a clean finished appearance
- Emergency exit and alert trigger points where the included Emergency label identifies the button for panic or duress activation, the selectable NO/NC contact connects to any alarm panel or monitoring system input, and the 1A at 12VDC rating handles direct relay coil loads without an intermediate relay
- Bilingual facilities requiring dual-language labeling where the included Push to Exit and Presione Para Salir adhesive labels cover English and Spanish identification requirements, the compact form factor fits alongside other controls in tight enclosures, and the 12 to 24VDC operating range connects to standard access control panel power supplies
What the SS-075C-PEQ Delivers
- Selectable NO/NC Momentary Contact: Field-selectable normally open or normally closed contact configuration adapts to any access control panel input without stocking separate button models. The momentary action returns to its default state when released for clean, repeatable signal pulses.
- 1A at 12VDC with 12-24VDC Operation: Contact rated at 1 amp at 12 volts DC handles direct relay coil loads and low-voltage control circuits. The 12 to 24VDC operating voltage range connects to standard access control and security system power supplies.
- Concealed Screw Terminals: Hidden screw terminal connections provide a clean, tamper-resistant installation appearance. The low-profile 3 x 15/16 x 5/8 inch off-white housing mounts flush against interior walls for discreet placement at exit points.
- Interchangeable Labels in English and Spanish: Three included adhesive labels cover Emergency, Push to Exit, and Presione Para Salir identification. Swap labels to match the application without ordering separate button models for emergency and exit functions.
