Ubiquiti UniFi Switch Ultra – USW-Ultra-60W
8-Port Compact Layer 2 Switch with 42W PoE Output and PoE++ Input
The Ubiquiti USW-Ultra-60W is a sleek and silent Layer 2 switch with 8 Gigabit Ethernet ports, designed for compact, high-efficiency UniFi deployments. It features four PoE+ output ports (802.3af/at), three data-only ports, and one PoE++ input port (802.3bt), eliminating the need for a bulky power brick. Managed via the UniFi Network application, this switch is ideal for home offices, small businesses, or remote edge setups where space and silence matter.
Key Features:
• 8 Gigabit RJ45 Ports: 4× PoE+ (802.3af/at), 3× data-only, 1× PoE++ input
• 42W Total PoE Budget: Power UniFi access points, cameras, or Talk/Access devices
• Powered by PoE++: Uses a single 802.3bt uplink—no external power adapter required
• Silent Operation: Fanless design with compact metal enclosure
• Cloud-Managed: Fully managed via UniFi Network app (web/mobile)
• Flexible Mounting: Includes wall-mount bracket and adhesive pads
Ideal For:
Small-scale UniFi deployments
Home networks and smart office spaces
Powering low-to-mid PoE devices
Noise-sensitive environments
Why Choose the USW-Ultra?
It delivers reliable PoE switching in an ultra-compact, fanless form factor—perfect for quiet environments and tight spaces where performance and efficiency are critical.
Key Highlights:
- ✅ 8 GbE ports: 4 PoE+ out, 3 data-only, 1 PoE++ in
- ✅ 42W total PoE output across 4 devices
- ✅ Powered via 802.3bt (PoE++) uplink—no separate power brick
- ✅ Compact, fanless, and cloud-managed with UniFi Network
Frequently Asked Questions:
Q: Does this switch require a power adapter?
A: No, it is powered by a PoE++ (802.3bt) uplink connection. No power brick is required.
Q: What types of devices can I power?
A: Any 802.3af/at PoE-compatible device such as UniFi access points, Protect cameras, Talk phones, or Access door controllers, within the 42W budget.
Q: Can this switch be mounted?
A: Yes, it includes adhesive pads and a wall-mount bracket for flexible installation.
