Camera
Max Resolution: 4 MP
Sensor: 1/2.7" CMOS
Min. Illumination: Colour: 0.003 lux (F1.6, AGC ON), 0 lux with IR
Day/Night: IR-cut filter with auto switch (ICR)
Shutter: Auto/Manual, 1 ~ 1/100000s
Adjustment Angle: Pan: 3°~360°, Tilt: 0° ~ 68°, Rotate: 3°~360°
WDR: 120 dB
S/N: >52 dB
Lens
Focal Length: 2.8 mm / 4.0 mm
Iris: F1.6
FOV:
2.8 mm - H: 101.1°, V: 55.3°, D: 111.1°
4.0 mm - H: 83.5°, V: 43.0°, D: 99.7°
Lens Type: Fixed
Iris Type: Fixed
DORI
2.8 mm: D: 63 m, O: 25.2 m, R: 12.6 m, I: 6.3 m
4.0 mm: D: 90 m, O: 36 m, R: 18 m, I: 9 m
Illuminator
Supplemental Light: IR
Illumination Distance: 30 m (98.4 ft)
Wavelength: 850 nm
Light Control: Auto/Manual
Video
Compression: Ultra 265, H.265, H.264, MJPEG
Profiles: H.264 Baseline/Main/High
Frame Rate:
Main Stream: Up to 4MP (2688×1520), Max 30fps
Sub Stream: 720P, D1, 640×360, 2CIF, CIF - Max 30fps
Third Stream: D1, 640×360, 2CIF, CIF - Max 30fps
Bit Rate: 128 Kbps to 16 Mbps
U-code: Supported
ROI: Supported
OSD: Up to 8
Privacy Mask: Up to 4 areas
Video Stream: Triple Streams
White Balance: Auto, Outdoor, Fine Tune, Sodium Lamp, Locked, Auto2
DNR: 2D/3D DNR
Smart IR: Yes
Flip: Normal, Vertical, Horizontal, 180°, 90° CW, 90° CCW
HLC: Supported
BLC: Supported
Defog: Digital
Intelligent Features
Intrusion Prevention: Line crossing, intrusion, enter/leave area (human, vehicle, non-motor vehicle classification)
People Counting: Flow and density monitoring
Events
Basic Detection: Motion, Ultra Motion, Tampering, Audio Detection
General Function: Watermark, IP Filtering, Access Policy, ARP Protection, RTSP/HTTP/User Authentication
Audio
Compression: G.711U, G.711A
Bitrate: 64 Kbps
Two-way Audio: Supported
Suppression: Supported
Sampling Rate: 8 kHz
Storage
Edge: microSD, up to 512 GB
Network: ANR, NAS (NFS)
Network
Protocols: IPv4/IPv6, IGMP, ICMP, ARP, TCP, UDP, DHCP, RTP, RTSP, RTMP, DNS, FTP, SNMP, PPPoE, and more
Integration: ONVIF (S/G/T/M), API, SDK
Users: Up to 32 (admin, common user, operator)
Security: HTTPS, TLS 1.2, Strong Password, Digest Auth, Logs, WSSE
Client: UNV-Link, UNV-Link Pro, EZStation
Browser: IE 10+, Chrome 45+, Firefox 52+, Edge 79+
Plug-in Free: Chrome 57+, Firefox 58+, Edge 16+
Interface
Audio I/O: 1 In (35 kΩ), 1 Out (600 Ω)
Alarm I/O: 1/1
Built-in Mic: Yes
Network: 1 × RJ45 10/100 Mbps
Reset Button: Yes
Certification
EMC: CE-EMC, FCC
Safety: CE LVD, CB, UL/CUL
Environment: CE-RoHS, WEEE
General
Power: DC 12V ±25%, PoE (802.3af)
Consumption: Max 4.5W
Interface: Ø5.5 mm coaxial power plug
Dimensions: Ø109 × 62 mm (Ø4.3” × 2.4”)
Weight: 0.22 kg (0.49 lb)
Storage Temp: -30°C to 60°C (-22°F to 140°F), ≤ 95% RH
Operating Temp: -30°C to 60°C (-22°F to 140°F), ≤ 95% RH
Surge Protection: 4 KV
Material: Metal + Plastic
Web Client Languages: 20 languages
