Asus NUC 13 Pro NUC13L3HV7 Barebone System - Core i7 13th Gen i7-1370P Tetradeca-core (14 Core) - RNUC13L3HV70000UI
Key Features
- 13th Generation Intel® Core™ i7/i5/i3 with integrated Intel® Iris® Xe Graphics or Intel® UHD Graphics, and Intel vPro® Technology for selected SKUs.
- 14 Processor Cores (6P+8E), 20 threads, 24MB Smart Cache, 35W TDP
- Dual HDMI 2.1and Thunderbolt™4 ports give businesses flexibility to connect up to 4K extended displays
- For Business, the fast memory up to 64GB dual-channel DDR4-3200 SODIMMs
- For professional-grade performance, the 13th Gen Intel Core™ i7-1370P processor features 14 cores (6P+8E), 20 threads, 24MB Intel® Smart Cache, and 35W TDP
- Qualified for 24x7 operation
- Wired and wireless connections are lightning fast with up to a 2.5Gbps Intel® Ethernet port and Intel® Wi-Fi 6E (Gig+)
Product Overview
Smaller, Faster, Better, AI Ready
The ASUS NUC brand represents a commitment to technological excellence, prioritizing innovative product design, to push the boundaries of performance and user experience.
Developed through a partnership between ASUS and Intel, the ASUS NUC product lines anchor on delivering uncompromised performance in the smallest form factors, backed by industry best quality and reliability, innovative modular designs, extended lifespan options, smart cooling solutions, and advanced AI capabilities. The versatility of the products shines through an array of configurations catering to diverse user needs, from developers, to power users, to casual home use. Positioned as the preferred choice for a variety of business applications, vertical industries, and everyday users, the ASUS NUC combines exceptional performance with essential features, aiming to shape the next generation of PC experiences.
With a focus on supporting diverse businesses and enhancing PC applications, the ASUS NUC aspires to deliver on the brand promise of delivering the Next Unit of Compute (NUC) and make a lasting impact in the ever-evolving tech landscape.
General Information
- Manufacturer: ASUS Computer International
- Manufacturer Part Number: RNUC13L3HV70000UI
- Brand Name: Asus
- Product Line: NUC 13 Pro
- Product Model: NUC13L3HV7
- Product Name: NUC 13 Pro Kit NUC13L3HV7 Barebone System
- Product Type: Barebone System
Technical Information
- AI-powered: Yes
Processor
- Processor Type: Core i7
- Processor Generation: 13th Gen
- Processor Model: i7-1370P
- Processor Core: Tetradeca-core (14 Core)
- Maximum Turbo Speed: 5.20 GHz
- 64-bit Processing: Yes
Chipset
- Chipset Manufacturer: Intel
Memory
- Maximum Memory Supported: 64 GB
- Memory Technology: DDR4 SDRAM
- Memory Standard: DDR4-3200/PC4-25600
- Total Number of Memory Slots: 2
Controllers
- Controller Type:
- Serial ATA
- NVMe
Display & Graphics
- Graphics Controller Model: Iris Xe Graphics
- Graphics Memory Technology: DDR4 SDRAM
- Graphics Memory Accessibility: Shared
Network & Communication
- Ethernet Technology: 2.5 Gigabit Ethernet
- Wireless LAN: Yes
- Wireless LAN Standard: IEEE 802.11ax
- Bluetooth: Yes
- Bluetooth Standard: Bluetooth 5.3
Interfaces/Ports
- HDMI: Yes
- Total Number of USB Ports: 4
- Number of USB 3.2 Gen 2 Ports: 3
- Network (RJ-45): Yes
- Number of SATA Interfaces: 1
- Number of Thunderbolt 4 Ports: 2
Operating System
- Operating System Supported:
- Windows 11 Home
- Windows 11 Pro
- Windows 10 IoT Enterprise
Power Description
- Maximum Power Supply Wattage: 120 W
- Thermal Design Power: 40 W
Physical Characteristics
- Color Family: Black
- Product Color: Black
- Height: 2.1"
- Width: 4.6"
- Depth: 4.4"
- Weight (Approximate): 1.30 lb
Miscellaneous
- Package Contents:
- NUC 13 Pro Kit NUC13L3HV7 Barebone System
- VESA Mount & Screws
- AC Power Adapter
- Power Cord
- Environmental Compliance: Restriction of Hazardous Substances (RoHS)
