AVer TR211 2 Megapixel Indoor Full HD Network Camera - Color - TAA Compliant - PATR211V3
Key Features
- 12x optical zoom for bringing the subject closer for maximum surveillance efficiency
- 46.80 mm maximum focal length provides incredible detail and how effective is your network camera
- Auto camera iris automatically opens or closes the iris to provide an image of the correct exposure
- f/1.6 maximum aperture for better light absorption and dependable, better-quality results
- Full HD recording format for stunning, vivid video results with maximum efficiency
- HDMI effectively and conveniently transmits both audio and video signals with one single cable to ensure hassle-free connectivity
- Network camera - Helps achieve high-quality video results
- Revolutionary image sensor - Joins multiple exposed patterns together and advanced planarization for minimized fluctuation
- Up to 1920 x 1080 resolution for surveillance in real-time
- Varifocal lens type to ensure maximum surveillance dependability and optimal performance
Product Overview
Exceptional Video Quality with Zero Compromises
The AVer TR211 AI Auto Tracking Camera delivers professional-grade lectures, sermons, trainings or whatever you need to stream! The 12X optical zoom, powerful 8MP camera and 1080p 60fps resolution offer the range and picture quality to produce the highest quality productions. The advanced artificial intelligence (AI) technology allows you to track your speaker (full or half body) or pre-set shoot zone without a dedicated camera operator. The TR211 is built on a new platform to provide improved performance that will enable AVer to continue to innovate. You can expect faster firmware upgrade, boot times, video initialization, and improved performance compared to previous model (TR311HWV2).
With PoE+, SRT, SDI, LAN, USB type B to PC, RS232, HDMI-Out, AVer control and management software, and compatibility with all popular video platforms, you have all you need to connect with ease in any environment.
Our industry-leading AVerCare warranty program offers 5-year protection and 24-hour replacement to give you total peace of mind.
Harness the Magic of NDI/HX3
Includes the most recent edition of the NDI protocol is NDI®version 3 (NDI®|HX3). Features 4Kp60 NDI output with latency less than 100ms.
Presenter tracking
Capture every interaction
Either track full body or half body
Simple click to track and manually follow an additional presenter via remote control or Web UI
Zone tracking
Establish preset zones
Create video focused on content
Enhance the capture of content on multiple displays
Hybrid mode
Camera auto switch between Presenter vs Zone mode
Combines the best features of Presenter and Zone mode
Flexibility of tracking presenter freely or fixed content
General Information
- Manufacturer: AVer Information Inc
- Manufacturer Part Number: PATR211V3
- Brand Name: AVer
- Product Model: TR211
- Product Name: AI Auto Tracking PTZ Camera
- Product Type: Network Camera
Technical Information
- HD Recording: Yes
- Recording Formats: Full HD
- Camera Iris:
- Auto
- Manual
- AI-powered: Yes
Display & Graphics
- Image Sensor Type: Exmor CMOS
- Image Sensor Size: 1/2.8"
- Color Supported: Color
- Field of View: DFOV : 80.6° (Wide) to 7.7° (Tele) HFOV : 72.8° (Wide) to 6.7° (Tele) VFOV : 44.1° (Wide) to 3.8° (Tele)
- Effective Camera Resolution: 2 Megapixel
Video
- Video Formats:
- H.264
- H.265
- MJPEG
- Maximum Video Resolution: 1920 x 1080
- Maximum Frame Rate: 60 fps
- Analog Video Signal Format: 3G-SDI
Audio
- Audio Support: Yes
Lens
- Lens Type: Varifocal
- Minimum Focal Length: 3.90 mm
- Maximum Focal Length: 46.80 mm
- Lens Included: Yes
- Minimum Aperture: f/2.8
- Maximum Aperture: f/1.6
- Optical Zoom: 12x
Exposure
- Shortest Shutter Speed: 1/10000 Second
- Longest Shutter Speed: 1/1 Second
Network & Communication
- Connectivity Technology: Wired
- Remote Management: Yes
- Ethernet Technology: Gigabit Ethernet
- Protocols:
- IPv4
- TCP
- UDP
- ARP
- ICMP
- IGMP
- HTTP
- HTTPS
- DHCP
- RTP/RTCP
- RTSP
- RTMP
- LLDP
- VISCA over IP
Interfaces/Ports
- USB: Yes
- HDMI: Yes
- Network (RJ-45): Yes
Power Description
- Maximum Power Consumption: 18 W
- Input Voltage: 12 V
- Power Source Type: PoE+
Physical Characteristics
- Mount Type: Ceiling Mount
- Height: 7.6"
- Width: 7.1"
- Depth: 5.7"
Environmental Conditions
- Minimum Operating Temperature: 32°F (0°C)
- Maximum Operating Temperature: 104°F (40°C)
- Minimum Storage Temperature: -4°F (-20°C)
- Maximum Storage Temperature: 140°F (60°C)
- Minimum Operating Humidity: 20%
- Maximum Operating Humidity: 80%
- Minimum Storage Humidity: 20%
- Maximum Storage Humidity: 95%
Miscellaneous
- Features:
- Auto Tracking
- Back Light Compensation (BLC)
- Wide Dynamic Range
- Auto Gain Control
- Noise Reduction
- Mirror
- 2D Noise Reduction
- 3D Noise Reduction
- White Balance
- PTZ
- Indoor/Outdoor: Indoor
- Package Contents:
- AI Auto Tracking PTZ Camera
- Remote Control
- RS-232 In/Out Cable
- Din 8 To D-Sub 9 Cable
- Power Adapter
- Power Cord
- 4 x Cable Ties
- 3 x M2 x 4 mm Screws
- 3 x M3 x 6 mm Screws
- 2 x 1/4'-20L 6.5mm Screws
- Cable Fixing Plate
- 2 x Ceiling Mount Brackets
- Drilling Paper
- Quick Start Guide
- TAA Compliant: Yes
Warranty
- Limited Warranty: 5 Year
- Additional Warranty Information:
Accessories 1 year
