Crown CDi DriveCore 4|300 Amplifier - 1200 W RMS - 4 Channel - NCDI4X300-U-US
Key Features
- Increases the strength of a weak electrical signal without affecting other characteristics
- Smartly manages power at 4 Ohm impedance to execute sound flow. So Indulge yourself in HQ audio output!
- Soothe yourself with low subs and soaring vocals at 20 Hz - 20 kHz frequency
- The 4 audio channels on 1200 W RMS output power significantly enhance the audio's sound quality
Product Overview
The CDi DriveCore Series is an evolution in amplification, providing an impressive mix of high-performance; rich feature set, and competitive cost. Using technology derived from our flagship Installed Sound amplifier (Crown DriveCore Install series), the CDi DriveCore 4|300 offers streamlined functionality to work in almost any small/medium sized installation such as restaurants, retail stores, and more. Designed for ease-of-use in a variety of applications, the 4|300 is a 4-channel amp that includes network control/monitoring, high-level DSP, front-panel interface, and support for driving up to 100Vrms speaker loads without requiring a transformer. The entire CDi DriveCore line comes pre-loaded with JBL speaker tunings to help make installations quicker and easier.
General Information
- Manufacturer: Harman International Industries, Inc
- Manufacturer Part Number: NCDI4X300-U-US
- Brand Name: Crown
- Product Line: CDi DriveCore
- Product Model: 4|300
- Product Name: Analog Input, 4 Channel, 300W per Output Channel
- Product Type: Amplifier
Technical Information
- Minimum Frequency Response: 20 Hz
- Maximum Frequency Response: 20 kHz
- Total Harmonic Distortion (THD): 0.4%
- Impedance: 4 Ohm
Audio
- Audio Channels: 4
- RMS Output Power: 1200 W
Network & Communication
- Ethernet: Yes
Power Description
- Operating Power Consumption: 350 W
Physical Characteristics
- Height: 3.5"
- Width: 19"
- Depth: 12.3"
- Weight (Approximate): 16.13 lb
Miscellaneous
- Country of Origin: China
- Environmentally Friendly: Yes
- Environmental Compliance: Waste Electrical and Electronic Equipment Directive (WEEE)
