Eaton Tripp Lite Series 10/100/1000 LC Multimode Fiber to Ethernet Media Converter, 550M, 850nm - N785-001-LC-MM
Key Features
- Auto detects Full/Half Duplex Transfer Mode
- Extends a Gigabit Ethernet signal up to 550 meters over Multimode Fiber Optic Cable
- Supports Multimode 50/125 cable up to 550M or 62.5/125 cable up to 400M
Product Overview
Tripp Lite's N785-001-LC-MM 10/100/1000 to Multimode Media Converter ( RJ45 to LC ) is an economical way to extend the distance of network nodes up to 550M by converting Cat5e UTP cables to Multimode Fiber Optic. The Media Converter features automatic MDI/MDI-X configuration, and the UTP port senses the network speed automatically. Auto-detects half or full duplex operation on the fiber port. Power supplied by small form factor AC adapter.General Information
- Manufacturer: Eaton Corporation
- Manufacturer Part Number: N785001LCMM
- Brand Name: Tripp Lite series
- Product Model: N785-001-LC-MM
- Product Name: 10/100/1000 LC Multimode Media Converter, 550M, 850nm
- Product Type: Transceiver/Media Converter
Interfaces/Ports
- Total Number of Ports: 2
- Network (RJ-45): Yes
- DVI: No
- USB: No
- Management Port: No
- Number of LC Ports: 1
- Number of Network (RJ-45) Ports: 1
Media & Performance
- Media Type Supported:
- Optical Fiber
- Twisted Pair
- Fiber Mode Supported: Multi-mode
- Fiber Optic Cable Wavelength: 850 nm
- Maximum Distance Supported: 0.55 km
Network & Communication
- Ethernet Technology: Gigabit Ethernet
- Network Technology:
- 10/100/1000Base-T
- 1000Base-SX
Physical Characteristics
- Form Factor: Desktop
- Height: 1"
- Width: 4.7"
- Depth: 2.8"
- Weight (Approximate): 1 lb
Miscellaneous
- Environmentally Friendly: Yes
- Country of Origin: China
Warranty
- Limited Warranty: 2 Year
