Eaton Tripp Lite Series USB-C Dock, Dual Display - 4K HDMI/mDP, VGA, USB 3.x (5Gbps), USB-A/C Hub, GbE, Memory Card, 100W PD Charging - U442-DOCK1
Key Features
- 3-year limited warranty
- Convert your MacBook, Chromebook, tablet or laptop into a versatile workstation via its USB-C or Thunderbolt 3 port. Recommended for connecting an external display, accessing Gigabit Ethernet, transferring data and displaying video.
- Ethernet port supports 10/100/1000 Mbps speeds
- Memory card slots for external memory access
- Mini DisplayPort, VGA and HDMI ports
- USB-A ports support data transfer rates up to 5 Gbps
- USB-C Power Delivery port supports power input up to 20V 3A
Product Overview
USB 3.1, generation 1 USB-C Docking Station turns your MacBook, Chromebook, tablet or laptop into a versatile workstation. By connecting its built-in cable to your device's USB-C or Thunderbolt 3 port, you'll be able to add an external display, access Gigabit Ethernet networks, transfer data, display video and more. Mini DisplayPort (mDP), VGA and HDMI ports allow you to connect an external display (one display at a time). The mDP and HDMI ports support UHD video resolutions up to 3840 x 2160 (4K x 2K) at 30 Hz. The VGA port supports HD video resolutions up to 1920 x 1200, including 1080p, at 60 Hz. Connect a Gigabit Ethernet cable (sold separately) to the RJ45 port to access true 10/100/1000 Mbps network speeds. A dedicated BC 1.2-compliant USB port provides up to 1.5A of fast-charging power. Micro SD and SD/MMC memory card slots provide access to external memory. A 3.5 mm audio jack is convenient for connecting speakers, headphones or a microphone to your connected device.General Information
- Manufacturer: Eaton Corporation
- Manufacturer Part Number: U442-DOCK1
- Brand Name: Tripp Lite series
- Product Model: U442-DOCK1
- Product Name: U442-DOCK1 Docking Station
- Packaged Quantity: 1 Each
- Product Type: Docking Station
Technical Information
- Connectivity Technology: Wired
- Device Supported:
- Tablet PC
- Notebook
Interfaces/Ports
- Host Interface: USB Type C
- Total Number of USB Ports: 3
- Number of USB 3.0 Ports: 3
- Network (RJ-45): Yes
- VGA: Yes
- Mini DisplayPort: Yes
- Microphone: Yes
- HDMI: Yes
Miscellaneous
- Package Contents:
- U442-DOCK1 Docking Station
- Owner's Manual
- Environmental Compliance: Restriction of Hazardous Substances (RoHS)
- Country of Origin: China
Warranty
- Limited Warranty: 3 Year
- Additional Warranty Information:
3 year limited warranty
