HPE SMART CHOICE ProLiant DL320 G11 1U Rack Server - 1 x Intel Xeon Gold 5416S 2 GHz - 64 GB RAM - NVMe Controller - P69302-005
Key Features
- 1 processors supported for optimal performance and maximum reliability in mission-critical server environments
- 2 Network (RJ-45) Ports eliminate the need for additional wiring, streamlining deployment and reducing installation costs
- 4 USB ports allow quick, high-speed data transfer for your convenience, making file sharing and backups effortless
- 4th Gen server generation delivers improved performance for faster, more efficient computing
- 800 W power supply unit (PSU) fulfills system power needs, ensuring smooth operation under heavy workloads
- DDR5 SDRAM memory technology enables efficient data movement across CPU cycles, improving throughput for demanding server workloads
- Gigabit Ethernet is ideal for frequent large file transfers, such as backups and replication, ensuring smooth and efficient operations
- Rack form factor delivers added reliability and structural integrity, supporting consistent performance in enterprise setups
- With 64 GB memory, improve system performance to execute complex applications smooth
Product Overview
HPE ProLiant DL320 Gen11
Are you looking to run edge AI workloads like Computer Vision that need GPU accelerators or distributed data solutions that require expandable storage? The HPE ProLiant DL320 Gen11 is a 1U 1P server with a unique compact and workload-driven modular design that is purpose-built for edge computing delivering exceptional performance at 1P economics and an excellent choice for both virtualized and containerized workloads.
Powered by 4th and 5th Gen Intel® Xeon® Scalable Processors with up to 60 cores and 270W, increased memory capability (up to 2 TB 5200 MT/s), and high-speed PCIe Gen5 supporting up to four single-wide GPUs (or two double-wide), the HPE ProLiant DL320 Gen11 server is a perfect low-cost, 1U 1P, performance solution. The HPE ProLiant Gen11 servers are engineered to optimize IT at the edge with a cloud operating experience, built-in security, and optimized performance for workloads to drive your business forward.
General Information
- Manufacturer: Hewlett Packard Enterprise
- Manufacturer Part Number: P69302-005
- Brand Name: HPE
- Product Line: ProLiant
- Product Series: DL320 G11
- Product Name: ProLiant DL320 G11 Server
- Product Type: Server
Processor
- Number of Processors Supported: 1
- Number of Processors Installed: 1
- Processor Type: Xeon Gold
- Processor Generation: 4th Gen
- Processor Model: 5416S
- Processor Core: Hexadeca-core (16 Core)
- Processor Speed: 2 GHz
- Cache: 30 MB
Chipset
- Chipset Manufacturer: Intel
- Chipset Model: C741
Memory
- Standard Memory: 64 GB
- Maximum Memory Supported: 2.04 TB
- Memory Technology: DDR5 SDRAM
- Total Number of Memory Slots: 16
- Number of Occupied Memory Slots: 2
- Error Checking: ECC
- Signal Processing: Registered (Buffered)
Controllers
- Controller Type: NVMe
- Controller Model: NS204i-u
I/O Expansions
- Number of Total Expansion Bays: 9
- Number of Internal 2.5" Bays: 8
- Number of Media Drive Bays: 1
- Number of SFF Bays: 8
- Hot Swappable Bays: Yes
- Total Number of Expansion Slots: 2
- PCI Express Details: 1 x16 FHHL PCIe Gen5; 1 OCP 3.0 Slot as default. 1 x16 FHHL PCIe Gen5 optional
Display & Graphics
- Graphics Memory Capacity: 16 MB
Network & Communication
- Ethernet Technology: Gigabit Ethernet
Interfaces/Ports
- Total Number of USB Ports: 4
- Network (RJ-45): Yes
- Number of Network (RJ-45) Ports: 2
- VGA: Yes
- Remote Management: Yes
- Remote Management Controller: HPE iLO6
Operating System
- Operating System Supported:
- Windows Server
- Red Hat Enterprise Linux
- SuSE Linux Enterprise Server
- Ubuntu
- Oracle Linux
- Citrix XenServer
- CentOS
Power Description
- Input Voltage:
- 120 V AC
- 230 V AC
- Number of Power Supplies Supported: 2
- Number of Power Supplies Installed: 2
- Plug/Connector Type: C13/C14
- Maximum Power Supply Wattage: 800 W
- Redundant Power Supply: Yes
- Hot Swappable Power Supply: Yes
Miscellaneous
- Package Contents:
- ProLiant DL320 G11 Server
- Rail Kit
- 6-foot IEC C-13/C-14 Jumper Cord
- Security Features:
- UEFI Secure Boot and Secure Start support
- Tamper-free updates - components digitally signed and verified
- Immutable Silicon Root of Trust
- Ability to rollback firmware
- FIPS 140-2 validation
- Secure erase of NAND/User data
- Common Criteria certification
- Configurable for PCI DSS compliance
- Embedded TPM (Trusted Platform Module) 2.0. Excluded for shipments to China.
- Advanced Encryption Standard (AES) and Triple Data Encryption Standard (3DES) on browser
- Bezel Locking Kit option
- Support for Commercial National Security Algorithms (CNSA)
- Chassis Intrusion detection option
- Secure Recovery - recover critical firmware to a known good state on detection of compromised firmware
- Energy Star: Yes
- Environmentally Friendly: Yes
- Energy Efficiency Certification: ENERGY STAR 4.0
- Energy Efficiency Compliance: Energy-related Products Directive Lot 9 (ErP Lot 9)
- Environmental Compliance: Waste Electrical and Electronic Equipment Directive (WEEE)
Physical Characteristics
- Form Factor: Rack
- Rack Height: 1U
- Height: 1.7"
- Width: 17.1"
- Depth: 23.8"
- Weight (Approximate): 36.84 lb
Warranty
- Limited Warranty: 3 Year
- Additional Warranty Information:
3-year parts, 3-year labor, 3-year onsite support with next business day response.
