In Win Micro-ATX Chassis - BL040.FF300TB3F
Key Features
- 11.5L Small Form Factor
- A small 11.5L SFF chassis with optimal thermal and acoustic performance.
- Excellent Thermal Solution
- High Compatibility
- Multi-Enjoyment
- New PPCT Excellent Thermal & Acoustic Solution
- Optimal Thermal Performance
Product Overview
Design Philosophy
A small 11.5L SFF chassis with optimal thermal and acoustic performance.
High Compatibility
It is compatible with standard desktop components, which makes the installation easier and provides a great expandability when needed.
Detachable Drive Bay Cage
For easy installation
Multi-Enjoyment
Designated Infrared Receiver position to support Media Center and optional internal amplifier.
Tool-Free
- Screwless Expansion Slots Clip
- Optional screwless design- ODD/FDD/HDD bays, expansion slots,and side cover clips for easy installation.
- Screwless ODD Bay Clips
- Screwless Top Cover Clips
- Screwless FDD/HDD Bays Clips
Excellent Thermal Solution
?PPCT
Optional the innovative partition plate cooling technology (PPCT) maximizes performance while providing a quiet and cooling environment.
?Cooling Fan
Built-in 80x80x25mm fan for better system cooling.
General Information
- Manufacturer: In Win Development, Inc
- Manufacturer Part Number: BL040.FF300TB3F
- Brand Name: In Win
- Product Series: BL
- Product Model: BL040
- Product Name: Micro-ATX Chassis
- Product Type: Computer Case
Technical Information
- Motherboard Supported:
- Micro ATX
- Mini ITX
- Number of Fans Supported: 1
- Fan Size Supported: 3.15"
- Features:
- Removable Air Filter
- Intrusion Switch
Bays
- Number of External 5.25" Bays: 1
- Number of External 3.5" Bays: 1
- Number of Internal 3.5" Bays: 2
- Number of Internal 2.5" Bays: 1
I/O Expansions
- Total Number of Expansion Slots: 4
Interfaces/Ports
- Total Number of USB Ports: 4
- USB Port Details:
- 2 x USB 3.0
- 2 x USB 2.0
- 4 x USB 2.0
- Front USB: Yes
- Total Number of Audio In Ports: 1
- Front Audio In: Yes
- Total Number of Audio Out Ports: 1
- Front Audio Out: Yes
Power Description
- Power Supply Installed: Yes
- Power Supply Wattage: 300 W
Physical Characteristics
- Color Family: Black
- Product Color: Black
- Product Material: Steel
- Cooler Type: Fan Cooler
- Form Factor: Desktop
- Maximum CPU Cooler Height: 2.83"
- Maximum GPU Length: 7.68"
- Height: 13"
- Width: 3.8"
- Depth: 16.1"
- Weight (Approximate): 13 lb
Warranty
- Limited Warranty: 2 Year
