Sharp PN-M982 98" 4K UHD Professional Display - PN-M982
Key Features
- Digital Signage Display - Ideal for rack, passageway, booth or display counter
- Direct LED backlight technology for a consistent picture quality from corner to corner
- Engages your customers and makes their viewing experience breathtaking with its 2160p content
- Experience luminescent visual images with LCD display
- Features a 4k Ultra HD 3840 x 2160 resolution
Product Overview
Create pixel perfect imagery with the high-end panel quality of the new fully commercial Sharp PN-M Series large format displays. By implementing premium features and focusing on creating impressionable digital signage experiences, the PN-M series gives customers an elite display option with its one-of-a-kind and proprietary SpectraView Engine capabilities, these displays offer out-of-the-box factory panel calibration, allowing for consistent visuals out of the box. On top of that, these products allow customers the modularity capabilities to customize their product based on their needs and application. The new series contain a full metal mechanical chassis, allowing for a more robust design necessary for commercial applications while maintaining the attractive aesthetics that allow the focus of onlookers to be on what matters - the message. Robust connectivity interface allows customers to have up-to-date connectivity options while also allowing for enhanced daisy chain capabilities when tying displays together for video or control signal distribution. The Sharp PN-M series boasts 550 cd/m2 brightness which is ideal for a majority of high end digital signage applications in restaurants, command and control, retail, healthcare and corporate environments when high-end and feature rich displays are necessary to convey important messaging.
General Information
- Manufacturer: Sharp Electronics
- Manufacturer Part Number: PN-M982
- Brand Name: Sharp
- Product Line: MultiSync
- Product Series: PN-M
- Product Model: PN-M982
- Product Name: PN-M982 98" 4K UHD Professional Display
- Product Type: Digital Signage Display
Technical Information
- Bezel Width (Top): 0.63"
- Bezel Width (Bottom): 0.63"
- Bezel Width (Left): 0.63"
- Bezel Width (Right): 0.63"
- Panel Technology: In-plane Switching (IPS) Technology
- Operation Hours: 24 Hours/7 Days
Display & Graphics
- Number of Screens: 1
- Viewable Screen Size: 98"
- Screen Size Class: 98"
- Display Screen Type: LCD
- High Dynamic Range (HDR): Yes
- High Dynamic Range (HDR) Type:
- PQ
- HLG
- HDR10
- Response Time: 8 ms
- Display Resolution: 3840 x 2160
- Orientation: Landscape/Portrait
- Backlight Technology: Direct LED
- Aspect Ratio: 16:9
Video
- Scan Format: 2160p
- Native Contrast Ratio: 1,200:1
- Brightness: 550 Nit
Network & Communication
- Ethernet: Yes
Interfaces/Ports
- USB: Yes
- HDMI: Yes
- DisplayPort: Yes
- Serial: Yes
- Number of HDMI Inputs: 2
- Number of DisplayPorts: 2
- DisplayPort Output: Yes
- RS-232C Input: Yes
- Number of HDMI 2.0 Ports: 2
Power Description
- Input Voltage:
- 120 V AC
- 230 V AC
Physical Characteristics
- VESA Mount Standard: 400 x 400
- Mount Type:
- Wall Mountable
- Table Mount
- Stand Mount
- Mount Surface: Wall
- Height: 49.2"
- Width: 86.4"
- Depth: 3.3"
- Weight (Approximate): 149.91 lb
Environmental Conditions
- Minimum Storage Temperature: -4°F (-20°C)
- Maximum Storage Temperature: 140°F (60°C)
- Minimum Operating Humidity: 20%
- Maximum Operating Humidity: 80%
- Minimum Storage Humidity: 10%
- Maximum Storage Humidity: 80%
Miscellaneous
- Application/Usage:
- Commercial
- Restaurant
- Command Center
- Retail
- Healthcare
- Corporate
- Industrial
- Energy Star: Yes
- Energy Efficiency Certification: ENERGY STAR 8.0
Warranty
- Limited Warranty: 3 Year
