StarTech Gigabit Fiber to RJ45 Ethernet Media Converter Dongle, USB Powered, SMF/MMF, Single/Multimode Optical Fiber, TAA - D01ML55U-FIBER-MEDIA
Key Features
- APPLICATIONS: Upgrade computers, switches, routers, or other equipment to fiber; Suitable for on-site network troubleshooting, field deployments, industrial automation, telecommunications, broadcasting, data centers, and remote networking
- DURABLE CONSTRUCTION: IP20-rated full-metal housing for enhanced durability; Metal RJ45 latch tab ensures a robust and secure connection; Flexible strain relief on attached USB cable; Spring-loaded dust cover protects port when not in use
- FIBER TO ETHERNET MEDIA CONVERTER: Converts Gigabit fiber to RJ45 copper in a compact form factor; No SFP/Cat6 cables required; Convenient built-in USB cable for power; Dimensions: 3.2x0.8x0.7in (82.4x20x17.5mm)
- SHORT & LONG RANGE FIBER: LC slot compatible w/Single-Mode (10km) & Multi-Mode (800m); Single speed 1Gbps for both fiber and RJ-45 ports; Status LEDs including LFPT (Link Fault Pass-Through) enables IT admins to monitor network connectivity
- TECH SPECS: Single speed 1Gbps; x1 LC port; x1 RJ45; LC duplex; Singlemode SMF (10km) & multi
Product Overview
This compact Gigabit Fiber to Ethernet Media Converter enables Cat6 or similar cabling to be upgraded to an EMI-free fiber connection. The TAA-compliant adapter is designed with a convenient built-in USB cable for power, making it a perfect choice when external power options are unavailable.
Simplified Installation
The unmanaged fiber media converter features a plug-and-play design that does not require additional software or settings to be changed. The metal housing features an IP20 rating and is an all-in-one construction with integrated LC fiber and RJ45 ports. The RJ45 side features a metal tab to ensure a reliable and secure fit and prevent accidental disconnections.
Network Features
The LC slot is compatible with Single-Mode (10km) and Multimode (800m) fiber cables up to 1Gbps. A spring-loaded tab protects the port when not in use. The converter supports LFPT (Link Fault Pass-Through), allowing IT administrators to monitor and assess network connectivity at a glance based on the LED behavior.
Compatibility
This LAN-to-fiber converter is ideal for upgrading computers, switches, routers, or other equipment from copper to fiber. It suits various applications, including field deployments, industrial automation, telecommunications, broadcasting, data centers, and remote networking. Experience reliable connectivity with EMI immunity over long distances with this compact (3.2Ã-0.8Ã-0.7in/82.39x20x17.5mm) and power-efficient (2.5W max) dongle.
General Information
- Manufacturer: StarTech.com
- Manufacturer Part Number: D01ML55U-FIBER-MEDIA
- Brand Name: StarTech.com
- Product Name: D01ML55U-FIBER-MEDIA
- Packaged Quantity: 1
- Product Type: Transceiver/Media Converter
Interfaces/Ports
- Total Number of Ports: 2
- Network (RJ-45): Yes
- USB: Yes
- Number of LC Ports: 1
- LC Port Type: Duplex
- Number of Network (RJ-45) Ports: 1
Media & Performance
- Media Type Supported:
- Twisted Pair
- Optical Fiber
- Fiber Mode Supported:
- Single-mode
- Multi-mode
- Fiber Optic Cable Wavelength: 1310 nm
- Maximum Distance Supported: 10 km
Network & Communication
- Ethernet Technology: Gigabit Ethernet
- Network Technology:
- 1000Base-T
- 1000Base-LX
Power Description
- Power Source: USB
- Power Consumption: 2.50 W
Physical Characteristics
- Form Factor: Compact
- Height: 0.7"
- Width: 3.2"
- Depth: 0.8"
- Weight (Approximate): 1.70 oz
Miscellaneous
- Package Contents:
- D01ML55U-FIBER-MEDIA
- 1 x Quick-Start Guide
- Environmental Compliance: Waste Electrical and Electronic Equipment Directive (WEEE)
- TAA Compliant: Yes
Warranty
- Limited Warranty: 2 Year
