StarTech.com 5m USB 2.0 Active Extension Cable - M/F - USB2AAEXT5M
Key Features
- Blue LED indicator x1 for Extension Cable and USB port connection status monitoring
- Fully shielded for error-free connections
- Plug-and-play, no driver required
- Universal external power source also included
- USB bus-powered
Product Overview
The USB2AAEXT5M5m Active USB 2.0 Extension Cable offers one USB-A male connector and one USB-A female connector, and provides an active extension of USB 2.0 devices of up to 5-meters (15-feet).
An all-in-one cable for overcoming distance restrictions as well as power source limitations, the active USB 2.0 extension cable incorporates bus-powered active circuitry to ensure performance beyond the length limits of standard USB cables. Plus you can daisy chain 4 cables for a total USB extension of up to 20-meters.
If necessary, the cable can be powered from a wall outlet using the Universal AC power adapter that wasprovided with the cable- this will allow you to use USB bus-powered devices that may require extra power.
The USB2AAEXT5Mrepeater cable supports the full USB 2.0 bandwidth of 480 Mbps, and is backed by StarTech.com's 2-year Warranty.
More from the Manufacturer
General Information
- Manufacturer: StarTech.com
- Manufacturer Part Number: USB2AAEXT5M
- Brand Name: StarTech.com
- Product Name: 5m USB 2.0 Active Extension Cable - M/F
- Packaged Quantity: 1 Each
- Product Type: Data Transfer Cable
Technical Information
- Cable Type: USB
- Cable Characteristic: Extension Cable
- Cable Length: 16.40 ft
- Connector Type on First End: USB 2.0 Type A - Male
- Connector Gender on First End: Male
- Connector on First End Details: 1 x 4-pin USB 2.0 Type A - Male
- Connector Type on Second End: USB 2.0 Type A - Female
- Connector Gender on Second End: Female
- Connector on Second End Details: 1 x 4-pin USB 2.0 Type A - Female
- Connector Plating: Nickel
- Shielding: Yes
- Device Supported:
- Power Adapter
- Wall Outlet
- American Wire Gauge: 24 AWG
- Features: Active
Physical Characteristics
- Color Family: Black
- Product Color: Black
- Jacket Material: Polyvinyl Chloride (PVC)
- Weight (Approximate): 0.46 lb
Miscellaneous
- Package Contents:
- 5m USB 2.0 Active Extension Cable - M/F
- 1 x Universal Power Adapter
- Environmentally Friendly: Yes
- Environmental Compliance: Restriction of Hazardous Substances (RoHS)
- Country of Origin: Taiwan
Warranty
- Limited Warranty: 2 Year
