Ubiquiti USW-24-POE Ethernet Switch - USW-24-POE
Key Features
- Auto-Sensing IEEE 802.3af/at PoE
- Fanless, Silent Thermal Cooling
- SFP Ports for Gigabit Fiber Connectivity
Product Overview
Expand and power your network with the UniFi® PoE Switch, part of the Ubiquiti® UniFi Enterprise System. It is available in two models:
- USW-16-POE 16 RJ45 ports with 2 SFP ports
- USW-24-POE 24 RJ45 ports with 2 SFP ports
Compact Form Factor
Measuring only 7.9" in depth, the UniFi PoE Switch is designed for convenient installation:
- Rack mounted in a SOHO rack cabinet
- Placed on a desktop
Fiber Connectivity
SFP ports enable network uplinks of up to 1 Gbps.
Fanless, Silent Cooling
The UniFi PoE Switch features fanless, silent thermal cooling, so it can be located in any workspace.
Switching Performance
The UniFi PoE Switch offers the forwarding capacity to simultaneously process traffic on all ports at line rate without any packet loss.
802.3af/at PoE
PoE support simplifies your network infrastructure and cabling. PoE ports offer 802.3af/at to power your PoE devices, such as UniFi APs and cameras.
General Information
- Manufacturer: Ubiquiti Inc.
- Manufacturer Part Number: USW-24-POE
- Brand Name: Ubiquiti
- Product Model: USW-24-POE
- Product Name: USW-24-POE Ethernet Switch
- Product Type: Ethernet Switch
Interfaces/Ports
- Total Number of Network Ports: 24
- Uplink Port: Yes
- Modular: Yes
- Port/Expansion Slot Details:
- 16 x Gigabit Ethernet PoE+
- 8 x Gigabit Ethernet Network
- 2 x Gigabit Ethernet Uplink
Media & Performance
- Media Type Supported:
- Optical Fiber
- Twisted Pair
- Ethernet Technology: Gigabit Ethernet
- Network Technology:
- 10/100/1000Base-T
- 1000Base-X
I/O Expansions
- Total Number of Expansion Slots: 2.0
- Expansion Slot Type: SFP (mini-GBIC)
- Number of SFP Slots: 2
Network & Communication
- Layer Supported: 2
Management & Protocols
- Manageable: Yes
Power Description
- Power Source: Power Supply
Physical Characteristics
- Compatible Rack Unit: 1U
- Form Factor:
- Rack-mountable
- Desktop
- Height: 1.7"
- Width: 17.4"
- Depth: 7.9"
- Weight (Approximate): 6.61 lb
Miscellaneous
- Package Contents:
- USW-24-POE Layer 3 Switch
- Rack Mount Hardware
- Environmentally Friendly: Yes
- Environmental Compliance: Waste Electrical and Electronic Equipment Directive (WEEE)
Warranty
- Limited Warranty: 1 Year
