Ubiquiti USW-Enterprise-24-PoE – 24-Port 2.5GbE Layer 3 PoE+ Switch
High-performance UniFi Layer 3 switch with 2.5GbE PoE+ ports, 10G uplinks, and touchscreen management for advanced enterprise networks.
The USW-Enterprise-24-PoE is a fully managed Layer 3 switch equipped with twenty-four PoE+ RJ45 ports (twelve 1G and twelve 2.5G), along with two 10G SFP+ uplinks. With a 400W total PoE budget and a 1.3" LCM touchscreen, it supports powerful switching capabilities for high-speed and high-density deployments, all managed seamlessly via the UniFi Network application.
Key Features:
• Ports: 12 × 1G PoE+ RJ45, 12 × 2.5G PoE+ RJ45
• Uplinks: 2 × 10G SFP+ ports
• Switching Capacity: 124 Gbps
• PoE Budget: 400W total (802.3at PoE+)
• Management: 1.3" touchscreen display and UniFi Network Application
• Form Factor: 1U rackmount (mounting hardware included)
Ideal For:
• High-density PoE+ access point and camera installations
• Aggregating 2.5G wired client or workstation connections
• Future-ready Layer 3 enterprise and campus deployments
Why You Should Use This:
• Provides 2.5GbE speed with full PoE+ support on all ports
• Includes 10G uplinks for fast backhaul to core switches
• Features built-in touchscreen for on-site status and diagnostics
Key Highlights:
- ✅ 24 × PoE+ RJ45 ports with mixed 1G and 2.5G support
- ✅ 2 × 10G SFP+ uplink ports
- ✅ 400W PoE budget with efficient power distribution
- ✅ Full UniFi Network Application integration
Frequently Asked Questions:
Q: Does this support UniFi Layer 3 features?
A: Yes, it includes DHCP server, VLAN routing, and static routes for UniFi-managed Layer 3 switching.
Q: Can it power UniFi WiFi 6E access points?
A: It supports 802.3at PoE+ (not PoE++), so it will power most UniFi APs except the highest-power 6E models.
Q: How is this device powered?
A: It uses internal AC power (100–240V) and supports USP RPS for redundant DC backup.
