Eaton 5S UPS 700VA 420 Watt 230V Tower UPS Sine Wave Battery Back Up LCD USB - 5S700G
Key Features
- Convenient form factor: Fit the 5S easily into tight spaces with its slim form factor. The versatile 5S can be used as a tower or as a desktop monitor stand
- Data protection: Safeguard your work and data with the UPS Companion software by gracefully shutting down your equipment during power outages
- Eco-Control: Save up to 30 percent on energy consumption by shutting down non-essential peripherals when the computer is turned off
- Power management: Enhance your power protection capabilities and ensure safe system shutdown with the Eaton UPS Companion software. The 5S interface is auto-recognized when plugged into computers with Windows, Macintosh and Linux environments
- Surge protection: Provide surge protection for network phone lines, cable TV and satellite applications
Product Overview
The compact Eaton 5S UPS delivers backup power for desktop PCs and workstations. The eco-control capability enables you save up to 30 percent in energy consumption. The 5S displays critical UPS information on battery time and outage tracking through a user-friendly LCD interface.
General Information
- Manufacturer: Eaton Corporation
- Manufacturer Part Number: 5S700G
- Brand Name: Eaton
- Product Series: 5S
- Product Name: 5S UPS
- Product Type: Line-interactive UPS
Technical Information
- Plug/Connector Type: IEC 60320 C14
- Receptacle Type: IEC 60320 C13
- Receptacle Detail: 6 x IEC 60320 C13
Power Description
- Load Capacity (VA): 700 VA
- Load Capacity (Watt): 420 W
- Input Voltage: 220 V AC
- Output Voltage: 230 V AC
Interfaces/Ports
- USB: Yes
Battery Information
- Number of Batteries: 1
- Battery Characteristics: Maintenance-free, Sealed
- Battery Chemistry: Lead Acid
- Backup/Run Time (Full Load): 2 Minute
- Backup/Run Time (Half Load): 12 Minute
Physical Characteristics
- Height: 9.8"
- Width: 3.4"
- Depth: 10.2"
- Form Factor: Tower
- Weight (Approximate): 13.10 lb
Miscellaneous
- Package Contents:
- 5S UPS
- USB Cable
- User Manual
- Country of Origin: Philippines
- Environmentally Friendly: Yes
- Environmental Compliance: Restriction of Hazardous Substances (RoHS)
Warranty
- Limited Warranty: 3 Year
