HPE 6100 24G Class4 PoE 4SFP+ 370W Switch - JL677A#ABA
Key Features
- Automated configuration and verification with Aruba NetEdit
- Compact and fanless 12 port model for quiet deployment
- Convenient built-in 1/10GbE uplinks and up to 370W of Class 4 PoE for support of IoT devices
- Enterprise-class Layer 2 connectivity with support for ACLs, robust QoS and static routing
- Simplify adds, moves and changes with colorless ports
- Software defined ready with REST APIs
Product Overview
Aruba 6100 Switch SeriesThe Aruba CX 6100 Switch Series is modern family of entry level access switches ideal for enterprise branch offices and SMB networks. Optimized for reliable, simple and secure access, the CX 6100 switches provide a convenient wired access solution for enterprise networks supporting IoT, mobile and cloud applications.
The CX 6100 series is based on the Aruba ASIC architecture with the programmable AOS-CX operating system used across the entire Aruba CX portfolio for a more consistent, more efficient operator experience. This layer 2 switch series has convenient builtin high speed uplinks with up to 370W of PoE to support IoT devices such as security cameras and wireless APs, and includes a compact and fanless model ideal for use in quiet work spaces. With robust QoS, support for static routing, and IPv6, the CX 6100 also simplifies ownership with no software licensing requirements..
General Information
- Manufacturer: Hewlett Packard Enterprise
- Manufacturer Part Number: JL677A#ABA
- Brand Name: HPE
- Product Series: 6100
- Product Name: 6100 24G Class4 PoE 4SFP+ 370W Switch
- Product Type: Ethernet Switch
Interfaces/Ports
- Total Number of Network Ports: 24
- Uplink Port: Yes
- Modular: Yes
- Port/Expansion Slot Details:
- 24 x Gigabit Ethernet PoE
- 4 x 10 Gigabit Ethernet Expansion Slot
Media & Performance
- Media Type Supported:
- Twisted Pair
- Optical Fiber
- Ethernet Technology:
- Gigabit Ethernet
- 10 Gigabit Ethernet
- Network Technology:
- 10/100/1000Base-T
- 10GBase-X
I/O Expansions
- Total Number of Expansion Slots: 4.0
- Expansion Slot Type: SFP+
- Number of SFP+ Slots: 4
Network & Communication
- Layer Supported: 3
Management & Protocols
- Manageable: Yes
Power Description
- PoE (RJ-45) Port: Yes
- PoE Budget: 370 W
- Power Source: Power Supply
- Number of Power Supplies Supported: 1
- Number of Power Supplies Installed: 1
- Power Consumption: 32.70 W
Physical Characteristics
- Compatible Rack Unit: 1U
- Form Factor:
- Rack-mountable
- Wall Mountable
- Height: 1.7"
- Width: 17.4"
- Depth: 10.6"
- Weight (Approximate): 9.24 lb
Miscellaneous
- Package Contents:
- 6100 24G Class4 PoE 4SFP+ 370W Switch
- Mounting Brackets
- Environmentally Friendly: Yes
- Environmental Compliance:
- Restriction of Hazardous Substances (RoHS)
- Waste Electrical and Electronic Equipment Directive (WEEE)
Warranty
- Limited Warranty: Lifetime
