Tripp Lite by Eaton UPS SmartPro 120V 2.2kVA 1.7kW Line-Interactive UPS Tower Extended run 3 DB9 ports Battery Backup - SMART2200NET
Key Features
- 120V output, Corrects brownouts and overvoltages from 87V to 140V
- 2 independently switchable output load banks
- 2.2kVA / 2200VA line interactive, extended-run tower UPS
- 3 DB9 communication ports (1 RS232 / 2 contact-closure)
- Front panel status LEDs with load and battery capacity display
- NEMA 5-15P input, 6 NEMA 5-15R outlets
Product Overview
Tripp Lite's SMART 2200NET intelligent, line interactive large tower UPS system protects servers, networking accessories and telecommunications equipment from blackouts, voltage fluctuations and transient surges. Large internal batteries offer 27 minutes half load runtime and 11 minutes fully loaded. Runtime is expandable with optional BP24V28-2U (limit 1) and BP24V70-3U external battery packs. 2200VA/1700 watt power handling capability supports a variety of networking, telecom and other sensitive electronic applications. Includes 6 protected outlets. Supports remote monitoring of UPS and site power conditions via built-in RS-232 enabled monitoring port, plus standard UPS monitoring via 2 built in contact closure ports. PowerAlert UPS monitoring and unattended shutdown software is available via free download. Built-in audible alarm and front panel LEDs indicate line power, battery power, battery charge level, load level, plus voltage regulation status. Network grade AC surge suppression protects equipment from damage and performance problems resulting from transient surges.
General Information
- Manufacturer: Eaton Corporation
- Manufacturer Part Number: SMART2200NET
- Brand Name: Tripp Lite series
- Product Line: SmartPro
- Product Name: SmartPro 2200VA UPS
- Product Type: Line-interactive UPS
Technical Information
- Plug/Connector Type: NEMA 5-15P
- Receptacle Type: NEMA 5-15R
- Receptacle Detail: 6 x NEMA 5-15R
- Cord Length: 8 ft
- Transfer Time: 4 ms
Power Description
- Load Capacity (VA): 2200 VA
- Load Capacity (Watt): 1700 W
- Input Voltage: 120 V AC
- Output Voltage: 120 V AC
- Waveform Type: Pulse-width Modulated Sine Wave
- Surge Energy Rating: 720 J
Management
- Network Management: SNMP Manageable
- Alarm: On Battery
Controls/Indicators
- Status Indicators: Includes 5 front panel LEDs to indicate BATTERY CHARGE LEVEL, AC LINE POWER STATUS, VOLTAGE REGULATION STATUS, UPS LOAD LEVEL and BATTERY LOW / REPLACE information
Battery Information
- Battery Chemistry: Lead Acid
- Backup/Run Time (Full Load): 11 Minute
- Backup/Run Time (Half Load): 27 Minute
- Battery Life: 6 Year
- Typical Battery Recharge Time: 4 Hour
Environmental Conditions
- Maximum Operating Temperature: 122°F (50°C)
Physical Characteristics
- Product Color: Gray
- Height: 17"
- Width: 9"
- Depth: 12.50"
- Form Factor: Tower
- Weight (Approximate): 80 lb
Miscellaneous
- Package Contents:
- SMART2200NET UPS System
- PowerAlert Software CD
- 3 x 6-ft. network cables
- Warranty information
- Instruction manual
- Software Included: PowerAlert Software
- Country of Origin: China
Warranty
- Limited Warranty: 3 Year
