Vertiv Liebert GXT5 UPS - 3kVA/2700W 208V | Online Rack Tower Energy Star L6-20P - GXT5-3KL620RT2UXL
Key Features
- 3-YEAR WARRANTY: 3-year comprehensive coverage including battery with options for 2-year extension.
- EASY-TO-USE INTERFACE: Tower/rack mount design with gravity sensing graphical color display.
- ENERGY EFFICIENT (up to 95%): Energy Star 2.0 certified with high normal operating efficiency.
- HIGH POWER FACTOR (0.9-1.0): More usable power allows more connected loads saving space and costs.
- REMOTE MANAGEMENT: Optional Vertiv RDU101 network communications card with advanced features.
Product Overview
The Vertiv Liebert GXT5 uninterruptible power supply (UPS) protects critical equipment against outages and every type of power disturbance. This 3kVA online double conversion UPS offers continuous power conditioning in centralized and edge locations. With high power factor (0.9-1.0), it allows more connected loads saving space and costs. This tower/rack mount UPS has an optional Vertiv RDU101 communications card for remote monitoring to help you make more informed decisions and faster event resolution. With the free Vertiv Power Insight software, you can consolidate your view of up to 100 distributed UPS units providing simple notification of status and events in a single pane of glass. This 208V in/ 208V out single phase UPS has scalable runtime options with matching external battery cabinets to give extra runtime during an outage to support critical equipment. This battery backup is ENERGY STAR 2.0 certified and comes with an intuitive gravity sensing full-color LCD display.General Information
- Manufacturer: Vertiv
- Manufacturer Part Number: GXT5-3KL620RT2UXL
- Brand Name: Vertiv Liebert
- Product Series: GXT
- Product Name: GXT5 3kVA 208V UPS
- Packaged Quantity: 1
- Product Type: Double Conversion Online UPS
Technical Information
- Plug/Connector Type: NEMA L6-20P
- Receptacle Type:
- NEMA L6-20R
- NEMA L6-15R
- Receptacle Detail:
- 2 x NEMA L6-20R
- 2 x NEMA L6-15R
- Cord Length: 10 ft
- Transfer Time: 0 ns
- Phase: Single Phase
- Application/Usage: Mission Critical Equipment
Power Description
- Load Capacity (VA): 3000 VA
- Load Capacity (Watt): 2700 W
- Input Voltage: 230 V AC
- Output Voltage: 208 V AC
- Input Frequency: 50 Hz
- Waveform Type: Pure Sine Wave
- Utility (AC) Mode Overload:
- >200% for 250ms
- 150-200% for 2 seconds
- 125-150% for 10 seconds
- 105-125% for 15 seconds
Controls/Indicators
- Status Indicators: LED/Full Color Graphic LCD
Interfaces/Ports
- Serial Port: Yes
- USB: Yes
- Network (RJ-45): Yes
Battery Information
- Battery Characteristics: Valve-regulated
- Battery Chemistry: Lead Acid
- Backup/Run Time (Full Load): 3 Minute
- Backup/Run Time (Half Load): 9 Minute
- Number of External Battery Cabinets: 1
- Backup/Run Time With External Battery Cabinet (Full Load): 17 Minute
- Backup/Run Time With External Battery Cabinet (Half Load): 43.50 Minute
- Hot Swappable: Yes
Environmental Conditions
- Environmental Sensors:
- Leak Detection Sensor
- Temperature Sensor
- Humidity Sensor
Physical Characteristics
- Rack Height: 2U
- Form Factor: Rack/Tower
- Weight (Approximate): 65.10 lb
Miscellaneous
- Package Contents:
- GXT5 3kVA 208V UPS
- 4 Post Fixed Rail Kit
- Tower Stand
- USB Cable
- Quick Start Guide
- Safety Instruction Manual
- Energy Star: Yes
- Country of Origin: China
- TAA Compliant: No
- Environmentally Friendly: Yes
- Environmental Compliance:
- Registration, Evaluation, Authorization and Restriction of Chemicals (REACH)
- Restriction of Hazardous Substances (RoHS)
Warranty
- Limited Warranty: 3 Year
