Vertiv Liebert GXT5 UPS 3kVA 208V L6-30P| Online Double Conversion Rack Mount/Tower | Energy Star Certified| Lead Acid| 1.0 PF (GXT5-3KL630RT2UXL) - GXT5-3KL630RT2UXL
Key Features
- Compact tower/rack mount design with intuitive, gravity sensing, colored graphic LCD display
- Energy Star 2.0 certified UPS helps reduce operation cost with high normal operating efficiency
- High Power Factor (0.9-1.0) provides more usable power and more connected loads, saves space and costs
- Remote management and configuration of UPS with optional Vertiv RDU101 network communication card
- Vertiv Liebert GXT5-3KL630RT2UXL: 2U double conversion online UPS with L6-30P Input Cord
Product Overview
The Vertiv Liebert GXT5-3KL630RT2UXL uninterruptible power supply (UPS) protects critical equipment against outages and power disturbances. This single-phase, 3kVA online double conversion UPS comes with an L6-30P Input Cord. It offers continuous power conditioning in centralized and edge locations. With a high power factor (0.9-1.0), it allows more connected loads, saving space and costs. This compact rack mount/tower UPS has an optional Vertiv RDU101 communications card for remote monitoring and control to help enable faster event resolution. With the free Vertiv Power Insight software, monitor up to 100 distributed UPS units and receive simple notifications of their status and events in one place. This UPS has scalable runtime options with matching external battery cabinets for extra runtime during an outage to support critical equipment. This battery backup is ENERGY STAR 2.0 certified and comes with an intuitive, gravity-sensing, full-color LCD screen.General Information
- Manufacturer: Vertiv
- Manufacturer Part Number: GXT5-3KL630RT2UXL
- Brand Name: Vertiv Liebert
- Product Series: GXT
- Product Name: GXT5 3kVA 208V UPS
- Packaged Quantity: 1
- Product Type: Double Conversion Online UPS
Technical Information
- Plug/Connector Type: NEMA L6-30P
- Receptacle Type:
- NEMA L6-30R
- NEMA L6-15R
- Receptacle Detail:
- 2 x NEMA L6-30R
- 2 x NEMA L6-15R
- Cord Length: 10 ft
- Transfer Time: 0 ns
- Phase: Single Phase
- Application/Usage:
- Mission Critical Equipment
- Data Center
Power Description
- Load Capacity (VA): 3000 VA
- Load Capacity (Watt): 3000 W
- Input Voltage: 208 V AC
- Output Voltage:
- 200 V AC
- 208 V AC
- 220 V AC
- 230 V AC
- 240 V AC
- Input Frequency: 50 Hz
- Waveform Type: Sine Wave
- Utility (AC) Mode Overload:
- >200% for 250ms
- 150-200% for 2 seconds
- 125-150% for 10 seconds
- 105-125% for 15 seconds
Controls/Indicators
- Status Indicators:
Full Color Graphic LCD / Diagnostic LEDs:
- Alarm
- Fault Indication
Interfaces/Ports
- Serial Port: Yes
- USB: Yes
- Network (RJ-45): Yes
Battery Information
- Battery Characteristics: Valve-regulated, Non-spillable
- Battery Chemistry: Lead Acid
- Backup/Run Time (Full Load): 3 Minute
- Backup/Run Time (Half Load): 9 Minute
- Number of External Battery Cabinets: 1
- Backup/Run Time With External Battery Cabinet (Full Load): 17 Minute
- Backup/Run Time With External Battery Cabinet (Half Load): 43.50 Minute
- Hot Swappable: Yes
Environmental Conditions
- Environmental Sensors:
- Leak Detection Sensor
- Temperature Sensor
- Humidity Sensor
Physical Characteristics
- Height: 3.3"
- Width: 16.9"
- Depth: 21.3"
- Rack Height: 2U
- Form Factor: Rack/Tower
- Weight (Approximate): 65.10 lb
Miscellaneous
- Package Contents:
- GXT5 3kVA 208V UPS
- 4 Post Fixed Rail Kit
- Tower Stand
- USB Cable
- Quick Start Guide
- Safety Instruction Manual
- Energy Star: Yes
- Country of Origin: China
- TAA Compliant: No
- Environmentally Friendly: Yes
- Environmental Compliance:
- Registration, Evaluation, Authorization and Restriction of Chemicals (REACH)
- Restriction of Hazardous Substances (RoHS)
Warranty
- Limited Warranty: 3 Year
- Additional Warranty Information: Opt. 2 year extension
