IOGEAR GCS1808 Combo KVM Switch - GCS1808
Key Features
- 8-Port VGA KVMP with USB and PS/2 Interface
- Auto Scan Mode to monitor connected computers
- Broadcast Mode to send commands to all connected computers
- Cascade up to 2 levels - control up to 128 computers from a single console
- Easy to operate - computer selection via front panel LED's, intuitive OSD (on screen display) and hotkeys
- Front USB Port - for system upgrades
- Maximum video resolution: up to 2048 x 1536
- Multi-platform OS support - Windows®, Mac, Oracle® Solaris and Linux®
- Rack mountable in a 19" (1U) system rack
- Security - 2 level password protection for OSD
Product Overview
The GCS1808 Combo KVM Switch allows access and control of up to 64 computers from a single console (keyboard, mouse, and monitor). As many as 8 additional switches can be cascaded bringing the total number of connected computers to 64 computers that can be controlled from a single keyboard-monitor-mouse console. A custom ASIC (patent pending) provides an auto-sensing function that recognizes the position of each station on the installation, eliminating the need to manually set the position with DIP switches.
General Information
- Manufacturer: IOGEAR, Inc
- Manufacturer Part Number: GCS1808
- Brand Name: IOGEAR
- Product Name: GCS1808 Combo KVM Switch
- Product Type: KVM Switchbox
Technical Information
- Number of Computers Supported: 8
Video
- Graphic Mode:
- VGA
- SVGA
- QXGA
- Maximum Video Resolution: 2048 x 1536
Physical Characteristics
- Form Factor: Rack-mountable
- Rack Height: 1U
- Height: 1.8"
- Width: 17"
- Depth: 6.3"
- Weight (Approximate): 5.58 lb
Miscellaneous
- Package Contents:
- GCS1808 Combo KVM Switch
- 2 x Custom KVM Cable Sets (1 USB & 1 PS/2)
- 1 x Console Cable
- 1 x Cascade Cable
- 1 x Firmware Upgrade Cable
- 1 x Grounding Wire
- 1 x Foot Pad Set (4 Pads)
- 1 x Power Adapter
- 1 x Standard Rack Mounting Kit
- 1 x Installation Guide
- 1 x Warranty Card
- Environmentally Friendly: Yes
- Country of Origin: Taiwan
- TAA Compliant: Yes
Warranty
- Limited Warranty: 3 Year
