StarTech.com 8 Port 1U Rackmount DVI USB KVM Switch - SV831DVIU
Key Features
- and restored when switching
- Auto-scan function cycles through computers sequentially
- Can be used with DVI to HDMI adapters to connect HDMI based systems
- Connects to USB-based computer systems
- Front panel push-buttons and Hot-key functions allow for easy switching
- OS independent - No software or drivers required
- Support for most combo/wireless keyboard and mice
- Supports DVI/HDMI resolutions up to 1920x1200
- Supports Mac and Sun keyboard mapping - Keyboard states automatically saved
- USB console interfaces for keyboard and mouse
Product Overview
The SV831DVIU 8-Port 1U Rack Mount DVI USB KVM Switch lets you control up to 8 USB-connected computers (each with DVI or HDMI display output) from a single keyboard, mouse and monitor.
The KVM switch offers maximum control, allowing you to switch computers using hot-key commands or front panel push-buttons. Supporting digital resolutions up to 1920x1200 via DVI or HDMI connection (using DVI to HDMI adapter - see accessories), the KVM provides the high resolutions recommended for newer displays, allowing you to take full advantage of your monitor/screen capability.
A perfect addition to any server room or software test lab, this 8-port switch can be rack-mounted into 1U of cabinet space.
This product is TAA compliant and backed by a Startech.com 3-year warranty with free lifetime technical support.
Note: This KVM supports digital signals only, and cannot be used with DVI-to-VGA adapters.
More from the Manufacturer
General Information
- Manufacturer: StarTech.com
- Manufacturer Part Number: SV831DVIU
- Brand Name: StarTech.com
- Product Name: 8 Port 1U Rack Mount DVI USB KVM Switch
- Packaged Quantity: 1 Each
- Product Type: KVM Switchbox
Technical Information
- Number of Computers Supported: 8
Video
- Graphic Mode: WUXGA
- Maximum Video Resolution: 1920 x 1200
Interfaces/Ports
- USB: Yes
- DVI: Yes
- Number of USB Ports: 10
- Number of DVI Ports: 9
Power Description
- Input Voltage Range: 110V AC to 240V AC
Physical Characteristics
- Form Factor: Rack-mountable
- Rack Height: 1U
- Height: 1.7"
- Width: 17.2"
- Depth: 7.1"
- Weight (Approximate): 5.51 lb
Miscellaneous
- Package Contents:
- 8 Port 1U Rack Mount DVI USB KVM Switch
- 1 x Set Rack-Mount Brackets
- 3 x Power Cords (NA/EU/UK) or AU in Australia
- 1 x User Manual
- Environmentally Friendly: Yes
- Country of Origin: Taiwan
- TAA Compliant: Yes
Warranty
- Limited Warranty: 3 Year
