Black Box USB 2.0 Extender 4 Port CATx - IC400A-R2
Key Features
- Control, interrupt, bulk, and isochronous at up to 480 Mbps.
- Extends both USB 2.0 and USB 1.1 up to 100 meters (328 ft) over standard CATx UTP cable
- Provides true plug-and-play capabilities, ready to operate right out of the box
- Reliably extend USB 1.0 or 2.0 signaling over CATx cable to remote USB devices
- True plug-and-play capabilities, ready to operate right out of the box
- Works with all USB device types
- Works with Windows®, Mac®OS, and Linux® operating systems
Product Overview
Get USB connectivity anywhere.Install your USB devices anywhere! Combine the 4-Port CATx USB Extender with additional USB hubs to connect up to 30 USB devices. An AC power adapter at the remote unit provides up to 1A max to the USB port.
Use it for any or all of the following applications:
- Industrial control
- KVM extension
- Digital signage
- Remote desktop USB connections
- Security Web camera and access control
- Medical Device connectivity
- USB Web device sharing: printing, scanning, storage
General Information
- Manufacturer: Black Box Corporation
- Manufacturer Part Number: IC400A-R2
- Brand Name: Black Box
- Product Name: USB 2.0 Extender 4 Port CATx
- Product Type: USB Extender
Technical Information
- Maximum Extended Range: 328.08 ft
- Maximum Data Transfer Rate: 60 MB/s
Interfaces/Ports
- Network (RJ-45): Yes
- Number of Network (RJ-45) Ports: 2
- USB: Yes
- Number of USB Ports: 4
Power Description
- Input Voltage: 24 V DC
Physical Characteristics
- Height: 1"
- Width: 3.9"
- Depth: 3"
Miscellaneous
- Package Contents:
- Local Extender Module
- Remote Extender Module
- USB Cable (2-meter)
- Remote Extender Module
- Power Adapter
- USB Power Cord
- Country of Origin: China
- Environmentally Friendly: Yes
- Environmental Compliance: Restriction of Hazardous Substances (RoHS)
Warranty
- Limited Warranty: 2 Year
