CyberPower PDU30BT8F8R Single Phase 100 - 125 VAC 30A Basic PDU - PDU30BT8F8R
Key Features
- Amps: 30A (Derated to 24A)
- Cord length (ft.): 12
- Dimensions (in.): 17.5W x 1.75H x 2.25D
- Frequency: 50Hz/60Hz
- Outlets: 16 NEMA 5-20R
- Phase: Single
- Plug type: NEMA L5-30P
- Size: 1U Rackmount
- Volts: 100-125V
- Warranty: Limited lifetime
Product Overview
The CyberPower PDU30BT8F8R, a 16-outlet (8 front, 8 rear) rackmount basic power distribution unit (PDU), provides 100-125V 30A output. It distributes power to 16 NEMA 5-20R receptacles from a single NEMA L5-30P twist lock plug with unfiltered electrical pass-through. Designed for datacenters and other electrically demanding applications, the PDU30BT8F8R has rugged, industrial-grade metal housing and a 12-foot AC power cord. It can be mounted either horizontally or vertically, includes a cord retention tray, and is ETL/RoHS certified. A limited lifetime warranty covers defects in materials and workmanship in the product under normal use and conditions.
General Information
- Manufacturer: CyberPower Systems, Inc
- Manufacturer Part Number: PDU30BT8F8R
- Brand Name: CyberPower
- Product Series: Basic PDU
- Product Model: PDU30BT8F8R
- Product Name: PDU30BT8F8R Single Phase 100 - 125 VAC 30A Basic
- Product Type: PDU
Technical Information
- PDU Type: Basic
- Phase: Single Phase
- Plug/Connector Type: NEMA L5-30P
- Receptacle Type: NEMA 5-20R
- Receptacle Detail: 16 x NEMA 5-20R
- Protection Type: Overload Protection
- Locking Receptacles: Cord Retention Tray
Power Description
- Input Voltage: 120 V AC
- Input Voltage Range: 100 V AC - 125 V AC
- Output Voltage:
- 100 V AC
- 125 V AC
- Output Voltage Range: 100 V AC - 125 V AC
- Input Current: 30 A
- Input Frequency: 60 Hz
Physical Characteristics
- Color Family: Black
- Product Color: Black
- Mounting Orientation: Horizontal
- Mount Type:
- Rack-mountable
- Wall-mountable
- Form Factor: Horizontal/Vertical
- Rack Height: 1U
- Cord Length: 12 ft
- Height: 1.8"
- Width: 17.5"
- Depth: 2.3"
- Weight (Approximate): 6 lb
Environmental Conditions
- Minimum Operating Temperature: 32°F (0°C)
- Maximum Operating Temperature: 95°F (35°C)
- Minimum Storage Temperature: 5°F (-15°C)
- Maximum Storage Temperature: 113°F (45°C)
Miscellaneous
- Package Contents:
- Basic PDU30BT8F8R 16-Outlets PDU
- Cord Retention Tray
- User Manual
- Screw Kit
- Cord Clip Kit
- Horizontal Mounting Brackets
- Vertical Mounting Brackets
- Product Registration Card
- Application/Usage:
- Network Device
- Server
- Energy Star: No
- Environmentally Friendly: Yes
- Environmental Compliance: Restriction of Hazardous Substances (RoHS)
Warranty
- Limited Warranty: Lifetime
