Illuminated Push to Exit Button with Adjustable 1-180 Second Timer, NO/NC Contacts, 3A at 24VDC Rating, Stainless Steel Single-Gang Faceplate, and Buzzer Output for Access Control Door Release
The Seco-Larm SD-7202GC-PTQ is an illuminated push to exit button with an adjustable timer from 1 to 180 seconds and selectable NO/NC contacts rated at 3A at 24VDC. The SD-7202GC-PTQ operates on 12-24VDC, features a 2-inch green illuminated square pushbutton on a brushed stainless steel single-gang faceplate, and includes a buzzer output for audible activation confirmation.
The built-in adjustable timer holds the output for 1 to 180 seconds after activation, allowing the connected maglock or electric strike to remain released long enough for door passage without requiring continuous button pressure. The five color-coded 12-inch wire leads with spade lugs simplify connection to access control panels, electric locks, and alarm systems.
Where the SD-7202GC-PTQ Fits
- Maglock and electric strike door release stations where the adjustable 1-180 second timer holds the lock release after a single button press, the NO/NC contacts connect to any access control panel input, and the stainless steel single-gang faceplate mounts on standard electrical boxes
- Commercial egress points requiring visual and audible confirmation where the green illuminated 2-inch pushbutton provides a visible exit indicator, the buzzer output confirms activation for the person exiting, and the 3A at 24VDC contact rating handles direct maglock and strike loads
- Schools, offices, and retail locations with timed door release where the timer prevents the door from remaining unlocked after the release period expires, the 12-24VDC operating range connects to standard access control power supplies, and the brushed stainless steel finish withstands daily use in high-traffic areas
What the SD-7202GC-PTQ Delivers
- Adjustable 1-180 Second Timer: Built-in timer adjusts from 1 to 180 seconds to hold the output after a single button press. The timed release keeps the connected lock disengaged for the set duration, then automatically re-engages without manual intervention.
- NO/NC Contacts at 3A/24VDC: Selectable normally open or normally closed contacts rated at 3 amps at 24VDC handle direct maglock, electric strike, and relay coil loads. The dual-contact configuration adapts to any access control panel input wiring scheme.
- Green Illuminated 2-Inch Pushbutton: The 2-inch green illuminated square button provides a visible exit indicator and easy target for users. The 12V 1.2W bulb provides 15,000 hours of rated life for reliable long-term illumination.
- Stainless Steel Single-Gang Faceplate: Brushed stainless steel single-gang faceplate mounts on standard electrical boxes and resists scratching, corrosion, and daily wear. Five color-coded 12-inch wire leads with spade lugs simplify wiring connections.
