StarTech 10/100 Multi Mode Fiber Copper Fast Ethernet Media Converter ST 2 km - MCM110ST2
Key Features
- Compatible with 3com, Cisco, Lucent and Nortel networks
- LED Indicators for simple Ethernet/Fiber network link monitoring
- Support flow control (Pause)
- Supports a maximum multi mode fiber optic cable distance of 2 km
- Supports full or half-duplex operation
- Supports IEEE 802.1q Tag VLAN pass thru
- Supports IEEE 802.3 10Base-T, 802.3u 100Base-TX and 100Base-FX industry standards
- Supports Link Fault Pass through (LFP)
- Supports Q in Q double tagged frame transparent
Product Overview
The MCM110ST2 10/100 Multi Mode ST Fiber Ethernet Media Converter (2 km) creates a cost-effective Ethernet to fiber link, transparently converting to/from 10Base-T or 100Base-Tx Ethernet signals and 100Base-Fx optical signals to extend an Ethernet network connection over a multimode fiber backbone.The ST media converter supports a maximum multimode fiber optic cable distance of 2km (1.2 miles), providing a simple solution for connecting 10Base-T/100Base-Tx Ethernet networks to remote locations using ST-terminated multimode fiber, while delivering solid network performance and scalability.
Easy to setup and install, this compact, value-conscious fast Ethernet media converter features auto-switching MDI and MDI-X support on the RJ45 UTP connections as well as manual controls for UTP mode, speed, Full and Half Duplex, as well as LFP (Link Fault pass-through) on/off.
Backed by a StarTech 2-year warranty and free lifetime technical support.
More from the Manufacturer
General Information
- Manufacturer: StarTech
- Manufacturer Part Number: MCM110ST2
- Brand Name: StarTech
- Product Name: 10/100 Multi Mode Fiber Copper Fast Ethernet Media Converter ST 2 km
- Packaged Quantity: 1 Each
- Product Type: Transceiver/Media Converter
Interfaces/Ports
- Total Number of Ports: 2
- Network (RJ-45): Yes
- Number of Network (RJ-45) Ports: 1
- Number of ST Ports: 1
- ST Port Type: Duplex
Media & Performance
- Media Type Supported:
- Optical Fiber
- Twisted Pair
- Fiber Mode Supported: Multi-mode
- Fiber Optic Cable Wavelength: 1310 nm
- Maximum Distance Supported: 2 km
Network & Communication
- Ethernet Technology: Fast Ethernet
- Network Technology:
- 10Base-T
- 100Base-FX
Power Description
- Power Source: AC Adapter
- Power Consumption: 2.40 W
- Plug/Connector Type: Type M
Physical Characteristics
- Form Factor: External
- Height: 0.8"
- Width: 3"
- Depth: 3.7"
- Weight (Approximate): 2.90 oz
Miscellaneous
- Package Contents:
- 10/100 Multi Mode Fiber Copper Fast Ethernet Media Converter ST 2 km
- 1 x Power Adapter
- 1 x Instruction Manual
- Environmentally Friendly: Yes
- Country of Origin: Taiwan
- TAA Compliant: Yes
Warranty
- Limited Warranty: 2 Year
