StarTech.com 2 Drive 2.5in Trayless Hot Swap SATA Mobile Rack Backplane - Storage bay adapter - black - HSB220SAT25B
Key Features
- 50,000+ insertion rating
- Aluminum construction
- Holds up to two SATA drives in a single 3.5" bay
- Includes a plastic protective film for the bottom side of hard drive
- Plug-and-Play and Hot-Swap compatible
- Power/Activity LED for each drive
- Support for SATA revision I/II/III (1.5/3.0/6.0 Gbps)
- Supports 2.5" form factor SATA hard drives (HDD) and solid state drives (SSD)
- Trayless design: drives are not mounted into separate trays/enclosures
Product Overview
This 3.5in SATA hard drive hot-swap bay allows you to install two 2.5in SATA hard drives (HDD) or solid state drives (SSD) in an available/unused 3.5in floppy drive bay.
Featuring a convenient "no mounting required /easy eject" feature (like a tape cartridge or floppy disk), the hard drive hot swap bay doesn't require that the drives be installed in a tray - making it the ideal solution for quick and easy drive removals and insertions as part of a system building process, or integration into rackmount systems or industrial environments.
To maximize performance and utilize the full speed potential of your SATA III hard drives, this HDD Backplane supports SATA III for transfer speeds up to 6 Gbps when paired with a compatible controller.
Also a perfect addition for operating system image deployment and any task that requires being able to quickly access large volumes of data on the fly, the hot swap bay provides everything you need to expedite important projects while maintaining a reliable storage solution.
With support for SATA HDD speeds up to 6.0 Gbps, this backplane is fully compatible with RAID installations to ensure maximum performance and versatility for enhanced storage applications.
More from the Manufacturer
General Information
- Manufacturer: StarTech.com
- Manufacturer Part Number: HSB220SAT25B
- Brand Name: StarTech.com
- Product Name: 2 Drive 2.5in Trayless Hot Swap SATA Mobile Rack Backplane
- Packaged Quantity: 1 Each
- Product Type: Drive Enclosure
Technical Information
- Number of Hard Drives Supported: 2
- Number of Hard Drives Installed: No
- Number of Solid State Drive Supported: 2
- Number of Solid State Drive Installed: No
Controllers
- Controller Type: Serial ATA
I/O Expansions
- Number of Total Expansion Bays: 2
- Number of 2.5" Bays: 2
Network & Communication
- Wireless LAN: No
Interfaces/Ports
- Drive Interface: SATA/600
- Host Interface: Serial ATA/600
Physical Characteristics
- Color Family: Black
- Product Color: Black
- Product Material: Aluminum
- Form Factor: Internal
- Compatible Drive Bay Width: 3.5"
- Height: 0.9"
- Width: 4"
- Depth: 5.3"
- Weight (Approximate): 10.10 oz
Miscellaneous
- Package Contents:
- 2 Drive 2.5in Trayless Hot Swap SATA Mobile Rack Backplane
- 2 x Lp4 To SATA And LED Adapter Cable
- 1 x 15-Pin SATA Power And LED Y Cable
- 2 x 7-Pin SATA Data Cable
- 2 x Hard Drive Protector Film
- 1 x Screw Kit
- 1 x Instruction Manual
- Country of Origin: Taiwan
- Environmentally Friendly: Yes
- Environmental Compliance:
- Restriction of Hazardous Substances (RoHS)
- Waste Electrical and Electronic Equipment Directive (WEEE)
- Registration, Evaluation, Authorization and Restriction of Chemicals (REACH)
Warranty
- Limited Warranty: 2 Year
