StarTech Cisco SFP-10G-LR Comp. SFP+ Module - 10GBASE-LR - 10GE Gigabit Ethernet SFP+ 10GbE Single Mode Fiber SMF Optic Transceiver - SFP10GLRST
Key Features
- 100% CISCO SFP-10G-LR COMPATIBLE: Works with Cisco switches like Firepower, ASR9000, C9300, C3850, C9500 and others
- OUTSTANDING SUPPORT: Backed by StarTech for the life of the module itself, not your equipment; our modules won't void your OEM support and with access to our Tech Advisors 5/24
- TECHNICAL SPECS: 10GBASE-LR
- 10 Gbps
- Single Mode (SMF)
- LC Connector
- 1310nm
- Digital Diagnostic Monitoring (DDM)
- Distances up to 10km (6.2mi)
- TESTED FOR OEM HOST COMPATIBILITY: Hot-swappable in Cisco routers and switches; DDM support reports the transceiver's status to most SNMP network management tools
- WORKS WITH MSA COMPLIANT SWITCHES: Also works with switch models from Ubiquiti, D-Link, Netgear, Supermicro, TP-Link and more that accept uncoded modules
Product Overview
The SFP10GLRST is a Cisco SFP-10G-LR compatible fiber transceiver module that has been designed, programmed and tested to work with Cisco™ brand switches and routers. It delivers dependable 10 GbE connectivity over fiber cable, for 10GBASE-LR compliant networks, with a maximum distance of up to 10 km (6.2 mi).Technical Specifications:
- Wavelength: 1310nm
- Maximum Data Transfer Rate: 10 Gbps
- Type: Single Mode Fiber
- Connection Type: LC Connector
- Maximum Transfer Distance: 10 km (6.2 mi)
- MTBF: 2,104,865 hours
- Power Consumption: Less than 1.3 Watts
- Digital Diagnostics Monitoring (DDM): Yes
StarTech SFPs
All StarTech SFP & SFP+ transceiver modules are backed by a lifetime warranty and free lifetime multilingual technical support. StarTech offers a wide variety of SFP modules and direct-attach SFP cables, providing the convenience and reliability you need to ensure dependable network performance.
More from the Manufacturer
General Information
- Manufacturer: StarTech
- Manufacturer Part Number: SFP10GLRST
- Brand Name: StarTech
- Product Name: Cisco SFP-10G-LR Compatible SFP+ Transceiver Module - 10GBASE-LR
- Product Type: SFP+
- Packaged Quantity: 1 Each
Technical Information
- Application/Usage:
- Optical Network
- Data Networking
Interfaces/Ports
- Total Number of Ports: 1
- Connector Type: LC
- Interfaces/Ports Details: 1 x LC Duplex 10GBase-LR Network
Media & Performance
- Media Type Supported: Optical Fiber
- Fiber Mode Supported: Single-mode
- Ethernet Technology: 10 Gigabit Ethernet
- Network Technology: 10GBase-LR
Physical Characteristics
- Form Factor:
- Hot-pluggable
- Hot-swappable
- Height: 0.5"
- Width: 0.5"
- Depth: 2.2"
- Weight (Approximate): 0.05 lb
Miscellaneous
- Compatibility:
- MSA Compliant
- ASR9000
- C9300
- C3850
- C9500
- Country of Origin: China
- Environmentally Friendly: Yes
Warranty
- Limited Warranty: Lifetime
