StarTech Dual Port Gigabit PCI Express Server Network Adapter Card - PCIe NIC - ST1000SPEXD4
Key Features
- Compatible with PCI Express Base Specification 2.0 (backward compatible with 1.0a/1.1)
- Configured with standard profile bracket, low profile/half-height bracket included
- Fully Compliant with IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, and supports IEEE 802.1Q VLAN tagging, IEEE 802.1P Layer 2 Priority Encoding and IEEE 802.3x Full Duplex Flow Control
- Supports Microsoft NDIS5 Checksum Offload (IP, TCP, UDP) and Large send Offload
- Supports Pair Swap / Polarity / Skew Correction
- Two 10/100/1000Mbps compatible RJ-45 Ethernet ports
- Up to 9K Jumbo Frame support
- Wake-on-LAN / Remote Wake-up support
Product Overview
Add dual Gigabit Ethernet ports to a client, server or workstation through a PCI Express slot. The ST1000SPEXD4 PCI Express Dual-Port Gigabit Network Card lets you add two gigabit Ethernet ports to a client, server or workstation through a single PCIe slot. Each port provides 10/100/1000 Mbps capable Ethernet and is fully compatible with IEEE 802.3/u/ab standards.Suitable for any standard PCI Express-enabled system, the 2-port Ethernet card supports full-duplex flow control for maximum data transfer speeds of up to 2000 Mbps - an ideal 2-port NIC for setting up dual-homed, or multi-homed host configurations providing added security to corporate networks.
The dual-port server adapter is compliant with the PCIe 2.0 standard and features support for Jumbo Frames and 802.1q VLAN tagging as well as Wake on LAN (WoL). The adapter includes an optional low-profile / half-height bracket that can be used for installation into a standard or small form-factor computer chassis.
Backed by a StarTech 2-year warranty and free lifetime technical support.
More from the Manufacturer
General Information
- Manufacturer: StarTech
- Manufacturer Part Number: ST1000SPEXD4
- Brand Name: StarTech
- Product Name: Dual Port Gigabit PCI Express Server Network Adapter Card - PCIe NIC
- Packaged Quantity: 1 Each
- Product Type: Gigabit Ethernet Card
Interfaces/Ports
- Host Interface: PCI Express x1
- Total Number of Ports: 2
- Number of Network (RJ-45) Ports: 2
Media & Performance
- Media Type Supported: Twisted Pair
- Maximum Data Transfer Rate: 1.95 Gbit/s
Network & Communication
- Network Technology: 10/100/1000Base-T
Physical Characteristics
- Form Factor: Plug-in Card
- Height: 4.7"
- Width: 0.7"
- Depth: 3.6"
- Weight (Approximate): 1.90 oz
Miscellaneous
- Package Contents:
- Dual Port Gigabit PCI Express Server Network Adapter Card - PCIe NIC
- 1 x Low Profile Bracket
- 1 x Driver CD
- 1 x Instruction Manual
- Device Supported: Server
- Environmentally Friendly: Yes
- Environmental Compliance:
- Restriction of Hazardous Substances (RoHS)
- Waste Electrical and Electronic Equipment Directive (WEEE)
- Registration, Evaluation, Authorization and Restriction of Chemicals (REACH)
- Country of Origin: China
Warranty
- Limited Warranty: 2 Year
