StarTech.com 2m (6ft) DisplayPort 1.2 Cable, 4K x 2K UHD VESA Certified DisplayPort Cable, DP Cable/Cord for Monitor, w/ Latches - DISPL2M
Key Features
- APPLICATIONS: Ideal for home/offices/boardrooms/conference rooms/classrooms; works with your professional workstations with FirePro™ S9000/7000, W8100/7100/5100 or R5000 graphic cards; Use with 1080p/UHD/4K monitors, projector or large display
- HIGH PERFORMANCE CABLE: This 2m (6ft) VESA Certified DisplayPort v1.2 cable supports 4K x 2K (3840x2400p 60Hz), 21.6 Gbps bandwidth, HBR2, 8Ch Audio, Multi-Stream Transport (MST), GTC for precise audio channel timing & 3D Stereo (2560x1600p 120Hz)
- QUALITY CONSTRUCTION: 28AWG wire with gold-plated connectors for improved signal integrity and reliability; Superior EMI shielding with Al-Mylar foil and copper braid provides higher quality video and audio; Backwards compatible with DP 1.1
- RELIABLE DESIGN: Durable ABS connectors with flexible PVC strain relief & jacket prevents fraying/damage due to bending or rough usage; Metal connector sub-structure provides EMI shielding; Latching DP connectors prevent accidental disconnection
- SPECS: 2 m (6 ft)
- Black
- DisplayPort v1.2
- DP Latching Male to Male
- 28 AWG
- PVC cable jacket, ABS connector shell
- Shield: Al-Mylar foil with Braid
- Protocols: HBR 2, MST, GTC
- Lifetime Warranty
Product Overview
The DISPL2M 2m DisplayPort™ 1.2 Cable with latches provides a secure, connection between your DisplayPort-equipped devices and is capable of providing higher performance than either HDMI® or dual link DVI.The DP cable supports high resolutions of up to 4k x 2k (4096 x 2160) @ 60Hz with a maximum HBR2 bandwidth of 21.6 Gbps. The cable also supports Multi-Stream (MST) for daisy chaining multiple monitors and provides optional audio support.
The DISPL2M is backed by StarTech.com's Lifetime Warranty, for guaranteed reliability and ensures that digitally protected content is displayed properly, with both HDCP and DPCP capability.
More from the Manufacturer
General Information
- Manufacturer: StarTech.com
- Manufacturer Part Number: DISPL2M
- Brand Name: StarTech.com
- Product Name: 2m Certified DisplayPort 1.2 Cable with Latches M/M - DisplayPort 4k
- Packaged Quantity: 1
- Product Type: A/V Cable
Technical Information
- Cable Type: DisplayPort
- Cable Length: 6.56 ft
- Connector Type on First End: DisplayPort 1.2 Digital Audio/Video - Male
- Connector on First End Details: 1 x 20-pin DisplayPort 1.2 Digital Audio/Video - Male
- Connector Type on Second End: DisplayPort 1.2 Digital Audio/Video - Male
- Connector on Second End Details: 1 x 20-pin DisplayPort 1.2 Digital Audio/Video - Male
- Connector Plating: Gold
- Shielding: Yes
- Device Supported:
- Audio/Video Device
- Monitor
- Workstation
- Notebook
- Graphics Card
- Projector
- American Wire Gauge: 28 AWG
- Data Transfer Rate: 21.6 Gbit/s
- Supported Resolution: 4096 x 2160
- Features:
- Molded
- EMI Protection
- Fray Resistant
- Damage Resistant
- Strain Relief
- Flexible
- HDCP
- DPCP
- Multi-Stream Transport (MST) Support
- Latching Connector
Physical Characteristics
- Color Family: Black
- Product Color: Black
- Jacket Material: Polyvinyl Chloride (PVC)
- Weight (Approximate): 0.32 lb
Miscellaneous
- Compatibility:
AMD Graphic Cards
- FirePro S9000
- 7000
- W8100
- 7100
- 5100
- R5000
- Environmentally Friendly: Yes
- Environmental Compliance: Restriction of Hazardous Substances (RoHS)
Warranty
- Limited Warranty: Lifetime
