StarTech.com 6 ft Mini DisplayPort to DisplayPort 1.2 Adapter Cable M/M - DisplayPort 4k - MDP2DPMM6
Key Features
- APPLICATIONS: Ideal for home/office/boardroom/classroom works w/laptop (with Mini-DP port)/professional workstations with AMD FirePro W9100/8100, Nvidia NVS 810/510 graphic card; UHD/4K monitor/projector/display; Microsoft Surface Pro 6/4
- MINI-DP to DISPLAYPORT 1.2 CABLE: This 6ft DisplayPort v1.2 cable supports 4K x 2K (3840x2400p 60Hz, 2560x1600p 120Hz), 21.6 Gbps bandwidth , HBR2, 8Ch Audio, Multi-Stream Transport (MST), GTC for precise audio channel timing & 3D Stereo
- QUALITY CONSTRUCTION: 32AWG wire with gold-plated connectors for improved signal integrity and reliability; Superior EMI shielding with Al-Mylar foil and copper braid provides higher quality video and audio; Backwards compatible with DP 1.1
- RELIABLE DESIGN: Durable ABS connectors with flexible PVC strain relief & jacket prevents fraying/damage due to bending or rough usage; Metal connector sub-structure provides EMI shielding; Latching DP connectors prevent accidental disconnection
- SPECS: 6.6 ft (1.8 meters); Black; DisplayPort v1.2; Mini-DP Male to Standard DP Latching Male; 32 AWG; PVC cable jacket, ABS connector shell; Shield: Al-Mylar foil with Braid; Protocols: HBR 2, MST, GTC; Backed for Life~
Product Overview
The mDP to DP cable supports high resolutions of up to 4k x 2k (3840 x 2160) @ 60Hz with a maximum HBR2 bandwidth of 21.6 Gbps. The cable also supports Multi-Stream (MST) for daisy chaining multiple monitors and provides optional audio support.
The MDP2DPMM6 is backed by StarTech.com's Lifetime Warranty, for guaranteed reliability and ensures that digitally protected content is displayed properly, with both HDCP and DPCP capability.
Please Note: Newer laptop and desktop computers (e.g. Apple®) come equipped with Thunderbolt™ ports only. Our Mini DP to DP Cables can be connected to the Thunderbolt ports, enabling you to connect your DP compatible displays.
More from the Manufacturer
General Information
- Manufacturer: StarTech.com
- Manufacturer Part Number: MDP2DPMM6
- Brand Name: StarTech.com
- Product Name: DisplayPort/Mini DisplayPort Audio/Video Cable
- Packaged Quantity: 1 Each
- Product Type: A/V Cable
Technical Information
- Cable Type: DisplayPort/Mini DisplayPort
- Cable Length: 6 ft
- Connector Type on First End: Mini DisplayPort 1.2 Digital Audio/Video - Male
- Connector Gender on First End: Male
- Connector on First End Details: 1 x 20-pin Mini DisplayPort 1.2 Digital Audio/Video - Male
- Connector Type on Second End: DisplayPort 1.2 Digital Audio/Video - Male
- Connector Gender on Second End: Male
- Connector on Second End Details: 1 x 20-pin DisplayPort 1.2 Digital Audio/Video - Male
- Connector Plating:
- Nickel
- Gold
- Jacket Type: CMG
- Device Supported:
- Audio/Video Device
- Notebook
- TV
- Monitor
- Projector
- HDTV
- Desktop Computer
- American Wire Gauge: 32 AWG
- Data Transfer Rate: 21.6 Gbit/s
- Supported Resolution: 3840 x 2160
- Features:
- DPCP
- HDCP
- EMI Protection
- Flexible
- Strain Relief
- Latching Connector
- Multi-Stream Transport (MST) Support
- Damage Resistant
- Fray Resistant
- Braided
Physical Characteristics
- Color Family: Black
- Product Color: Black
- Connector Material: ABS
- Shielding Material: Aluminum Mylar Foil
- Jacket Material: Polyvinyl Chloride (PVC)
- Weight (Approximate): 0.15 lb
Miscellaneous
- Environmentally Friendly: Yes
- Environmental Compliance:
- Restriction of Hazardous Substances (RoHS)
- Waste Electrical and Electronic Equipment Directive (WEEE)
- Registration, Evaluation, Authorization and Restriction of Chemicals (REACH)
- Country of Origin: Vietnam
Warranty
- Limited Warranty: Lifetime
