System Sensor CS-24W White Ceiling-Mount Horn/Strobe
The System Sensor CS-24W is a ceiling-mount horn/strobe that delivers reliable audible and visual emergency signaling with tamperproof field-selectable settings. Designed for versatile use in fire protection systems, this white unit offers selectable candela outputs of 15, 30, 75, 95, 115, and 150 to meet varying installation requirements. With low current consumption and easy-to-change tone and volume switches, this device simplifies installation while enhancing performance.
Engineered for flexibility, the CS-24W includes a Super-Slide® mounting bracket for faster wiring, Checkmate® instant voltage verification, and synchronization capabilities via the Gentex AVSM Control Module. The unit allows for temporal 3 or continuous tones, and supports both mechanical and 2400Hz sound options, all adjustable via field switches. Compatible with the CLNGBB ceiling surface-mount back box.
Key Highlights:
- Low current consumption with nominal 24VDC operation
- Field-selectable candela settings: 15, 30, 75, 95, 115, 150
- Switch options for mechanical or 2400Hz tone
- Continuous or temporal 3 pattern settings
- High or low dBA output options
- Super-Slide® bracket simplifies supervision testing
- Checkmate® instant voltage verification
- Surface mount using CLNGBB (sold separately)
- White finish with tamperproof re-entrant grill
Ideal For:
Indoor ceiling-mounted fire protection installations that require dependable horn/strobe signaling and simplified field customization.
Why You Should Use This:
The CS-24W combines high performance, flexible configuration, and low maintenance to support efficient emergency communication while reducing installation time and cost.
