Eaton Tripp Lite Series 550VA 300W Standby UPS - 10 NEMA 5-15R Outlets, 120V, 50/60 Hz, USB, 5-15P Plug, Desktop/Wall Mount - INTERNET550U
Key Features
- $100,000 Ultimate Lifetime Insurance
- 10 NEMA 5-15R outlets power and protect PC, home theater or digital signage equipment
- 3-year limited warranty
- High >98% efficiency with low BTU ratings saves electricity and lowers your energy costs
- Home-friendly alarm remains silent in backup mode, sounding only when imperative
- Keeps AC power running during blackouts to allow time for file saves and safe shutdown
- Protects equipment against blackouts, brownouts, overvoltages, surges and line noise
Product Overview
UPS offers standby protection for PCs and peripherals to prevent data loss and system downtime by providing battery-supported AC output during brownouts and blackouts. Two of the 8 output receptacles are widely spaced to accommodate large transformer plugs. Four outlets with full battery support and surge suppression protect computers, monitors and other vital system components from loss of power. Four additional outlets with surge suppression-only are ideal for printers and other accessories not requiring battery support. Single-line, telephone suppression jacks protect modem or other peripherals with a standard dialup or DSL phone line connection. HID-compliant USB interface enables integration with built-in power management and auto-shutdown features of Windows and Mac OS X. Audible alarm and front panel LEDs offer status information regarding line and battery power operation. 550VA/300 watt power handling ability supports entry-level PCs for up to 17 minutes during power failures.General Information
- Manufacturer: Eaton Corporation
- Manufacturer Part Number: INTERNET550U
- Brand Name: Tripp Lite series
- Product Line: Internet Office
- Product Model: INTERNET550U
- Product Name: Internet Office INTERNET550U 550VA UPS
- Packaged Quantity: 1 Each
- Product Type: Standby UPS
Technical Information
- Plug/Connector Type: NEMA 5-15P
- Receptacle Type: NEMA 5-15R
- Receptacle Detail: 10 x NEMA 5-15R
- Number of Battery & Surge Outlets: 5
- Number of Surge-only Outlets: 5
- Dataline Protection:
- RJ-11
- RJ-45
- Cord Length: 5 ft
- Transfer Time: 6 ms
- EMI/RFI Noise Filter: Yes
- Phase: Single Phase
- Energy Saving: Greater than 95% efficiency - GREEN UPS
- Application/Usage:
- Home/Office
- Media Center
- Commercial
- Computer
- Router
- Printer
- Storage Device
- TV
- Blu-ray Player
- Gaming Console
- Media Player
- DVR
- Audio System
Power Description
- Load Capacity (VA): 550 VA
- Load Capacity (Watt): 300 W
- Input Voltage: 120 V AC
- Input Current: 12 A
- Output Voltage:
- 110 V AC
- 115 V AC
- 120 V AC
- Output Frequency: 60 Hz
- Waveform Type: Pure Sine Wave
- Surge Energy Rating: 316 J
Management
- Alarm:
- Low Battery
- Fault
- Overload
- Replace Battery
Controls/Indicators
- Status Indicators:
1 x Status LED reports operating mode and fault status
Interfaces/Ports
- USB (HID Compliant) Port: Yes
Battery Information
- DC System Voltage: 12 V DC
- Backup/Run Time (Full Load): 1.20 Minute
- Backup/Run Time (Half Load): 5 Minute
- Typical Battery Recharge Time: 6.50 Hour
- Replaceable Battery: Yes
Environmental Conditions
- Maximum Operating Elevation: 10000 ft
- Storage Temperature: 5°F (-15°C) - 113°F (45°C)
Physical Characteristics
- Height: 4.1"
- Width: 4.3"
- Depth: 7.3"
- Form Factor: Ultra-compact Desktop/Tower/Wall Mount
- Weight (Approximate): 3.97 lb
Miscellaneous
- Package Contents:
- Internet Office INTERNET550U 550VA UPS
- USB cable
- Owner's Manual
- Software Included: PowerAlert Software
- Country of Origin: China
- Environmental Compliance: Restriction of Hazardous Substances (RoHS)
Warranty
- Limited Warranty: 3 Year
- Additional Warranty Information:
2 year warranty.
- 100,000connected equipment insurance (USA, Puerto Rico & Canada Only).
