CyberPower CP550SLG Standby UPS Systems - CP550SLG
Key Features
- $100,000
- 120 VAC ± 5%
- 3 year
- 550 VA / 330 W
- 8 × NEMA 5-15R
- Capacity:
- Communication ports:
- Connected Equipment Guarantee:
- Management software:
- NEMA 5-15P, 5 ft. cord
- Outlet types:
- Output:
- Plug type & cord:
- PowerPanel® Personal
- Simulated Sine Wave
- Standby
- Topology:
- USB
- Warranty:
- Waveform:
Product Overview
A compact UPS with standby topology, the CyberPower Standby CP550SLG provides battery backup (using simulated sine wave output) and surge protection for desktop computers, workstations, networking devices, and home entertainment systems. During power interruptions, the CP550SLG offers reliable power protection and battery backup. The CP550SLG comes with a three-year warranty and a ,100,000 Connected Equipment Guarantee.
General Information
- Manufacturer: CyberPower Systems, Inc
- Manufacturer Part Number: CP550SLG
- Brand Name: CyberPower
- Product Series: Standby UPS
- Product Model: CP550SLG
- Product Name: CP550SLG Standby UPS Systems
- Product Type: Standby UPS
Technical Information
- Plug/Connector Type: NEMA 5-15P
- Receptacle Type: NEMA 5-15R
- Receptacle Detail: 8 x NEMA 5-15R
- Number of Battery & Surge Outlets: 4
- Number of Surge-only Outlets: 4
- Dataline Protection: RJ-11
- Overload Protection: Yes
- Cord Length: 5 ft
- Transfer Time: 4 ms
- EMI/RFI Noise Filter: Yes
- Energy Saving: GreenPower UPS™ High-Efficiency Design
- Application/Usage:
- Desktop Computer
- Workstation
- Home Theater
- Electronic Equipment
- Home Network
- Router
- Modem
- VoIP Device
Power Description
- Load Capacity (VA): 550 VA
- Load Capacity (Watt): 330 W
- Input Voltage: 120 V AC
- Input Voltage Range: 96 V AC - 140 V AC
- Output Voltage: 120 V AC
- Input Frequency: 60 Hz
- Output Frequency:
- 50 Hz
- 60 Hz
- Waveform Type:
- Sine Wave
- Simulated Sine Wave
- Surge Energy Rating: 890 J
- Circuit Breaker: Yes
- Output Power Factor: 0.6
Management
- Alarm: Battery Mode
Controls/Indicators
- Status Indicators: LED Indicators: Power On
Interfaces/Ports
- Serial Port: No
- USB: Yes
- USB (HID Compliant) Port: Yes
Battery Information
- Number of Batteries: 1
- Battery Characteristics: Sealed
- Battery Chemistry: Lead Acid
- Battery Size: 12V
- Battery Capacity: 5500 mAh
- Backup/Run Time (Full Load): 2 Minute
- Backup/Run Time (Half Load): 8 Minute
- Typical Battery Recharge Time: 8 Hour
- Replaceable Battery: No
Environmental Conditions
- Storage Temperature: 5°F (-15°C) - 113°F (45°C)
- Operating Humidity: 0% - 90%
- Minimum Operating Temperature: 32°F (0°C)
- Maximum Operating Temperature: 104°F (40°C)
Physical Characteristics
- Product Color: Black
- Height: 5.8"
- Width: 9.8"
- Depth: 3.3"
- Form Factor: Compact
- Weight (Approximate): 7.50 lb
Miscellaneous
- Package Contents:
- Standby CP550SLG 550 VA Desktop UPS
- User Manual
- USB A+B Type Cable
- Warranty Registration Card
- Software Included: PowerPanel Personal Edition UPS Management Software
- Energy Star: No
- Environmentally Friendly: Yes
- Environmental Compliance: Restriction of Hazardous Substances (RoHS)
Warranty
- Limited Warranty: 3 Year
