APC Smart-UPS X, Line Interactive, 3kVA, Rack/tower convertible 2U, 100V-127V, 3x 5-15R+3x 5-20R+1x L5-30R NEMA, NMC, Extended runtime, W/rail kit - SMX3000RMLV2UNC
Key Features
- 1-Year Secure Network Management Card subscription included
- 2880VA/2700W line interactive pure sine wave 2U rack/tower UPS (rail kit included)
- Add up to 10 external battery packs (SMX120RMBP2U)
- Automatic Voltage Regulation keeps output voltage within acceptable user selectable levels
- Graceful shutdown of physical servers, virtual machines and HCI clusters
- Ideal for servers, storage, networking & commercial applications
- Preinstalled NMC for network-based UPS monitoring & management
- User-selectable low voltage setting of 100V-127V
Product Overview
This APC Smart-UPS is designed for IT managers or network administrators to maintain business uptime, data transfer and continuity during prolonged power outages. The 2880VA line interactive 2U rack/tower UPS provides pure sine wave power to support critical electronics during power disruptions. The SMX comes with NEMA L5-30P input, 3x NEMA 5-15R, 3x NEMA 5-20R and 1x NEMA L5-30R outlets. The UPS has a preinstalled Network Management Card for UPS network-based monitoring and management. The Smart-UPS comes with PowerChute Network Shutdown that provides graceful shutdown of physical servers, virtual machines, and HCI clusters. Use the intuitive LCD interface and PowerChute software to configure settings and monitor usage. This uninterrupted power supply can connect to EcoStruxure IT or third-party centralized management platforms. The SMX3000RMLV2UNC converts from a tower or stand-alone UPS to a rack mount UPS, offering flexibility in various installations. The SMX UPS has a 3-year warranty, and the built-in lead-acid battery has a 2-year warranty. This is compatible with dedicated user-replaceable battery, and the APC replacement battery cartridge helps restore UPS performance to the original specifications. The Smart-UPS comes with a pair of tower-mounting stabilizing feet and rack-mounting brackets. It comes with APC temperature sensor AP9335T for monitoring temperature. The 3 switchable outlet groups allow more granular management of the power supplied to your devices. The Emergency Power Off feature enables the UPS to remotely shutdown during emergencies.
General Information
- Manufacturer: Schneider Electric SA
- Manufacturer Part Number: SMX3000RMLV2UNC
- Brand Name: APC by Schneider Electric
- Product Line: Smart-UPS
- Product Series: X
- Product Model: SMX3000RMLV2UNC
- Product Name: Smart-UPS X SMX3000RMLV2UNC 3000 VA Rack-mountable UPS
- Product Type: Line-interactive UPS
Technical Information
- Plug/Connector Type: NEMA L5-30P
- Receptacle Type: NEMA L5-30P
- Receptacle Detail:
- 1 x NEMA L5-30R
- 3 x NEMA 5-15R
- 3 x NEMA 5-20R
- Number of Battery & Surge Outlets: 7
- Cord Length: 8 ft
- Transfer Time: 4 ms
Power Description
- Load Capacity (VA): 2880 VA
- Load Capacity (Watt): 2700 W
- Input Voltage: 120 V AC
- Input Current: 15 A
- Output Voltage: 120 V AC
- Waveform Type: Sine Wave
- Surge Energy Rating: 540 J
Management
- Network Management: SNMP Manageable
Interfaces/Ports
- Serial Port: Yes
- USB: Yes
Battery Information
- Battery Characteristics: Spill-proof, Maintenance-free
- Battery Chemistry: Lead Acid
- Backup/Run Time (Full Load): 6 Minute
- Backup/Run Time (Half Load): 18 Minute
- Hot Swappable: Yes
- Typical Battery Recharge Time: 3 Hour
Physical Characteristics
- Product Color: Black
- Height: 3.3"
- Width: 17"
- Depth: 26.3"
- Rack Height: 2U
- Form Factor: Rack-mountable
- Weight (Approximate): 84.77 lb
Miscellaneous
- Package Contents:
- Smart-UPS X SMX3000RMLV2UNC 3000 VA Rack-mountable UPS
- CD with software
- Documentation CD
- Installation guide
- Rack mounting brackets
- Rack mounting hardware
- Rack mounting support rails
- Removable support feet
- Smart UPS signalling RS-232 cable
- USB cable
- Web/SNMP management card
- Country of Origin: Philippines
- Environmentally Friendly: Yes
- Environmental Compliance: Restriction of Hazardous Substances (RoHS)
Warranty
- Limited Warranty: 3 Year
- Additional Warranty Information: UPS: 36 month(s)|Battery: 24 month(s)
