APC Smart-UPS X, Line Interactive, 3kVA, Rack/tower convertible 2U, 208V-230V, 8x C13+1x C19 IEC, SmartSlot, Extended runtime - SMX3000RMHV2U
Key Features
- 3kVA/2700W line interactive pure sine wave 2U rack/tower UPS (rail kit included)
- Add up to 10 external battery packs (SMX120RMBP2U)
- Automatic Voltage Regulation keeps output voltage within acceptable user selectable levels
- Graceful shutdown using serial or USB cables via PowerChute Serial Shutdown
- Ideal for servers, storage, networking & commercial applications
- User-selectable high voltage setting of 200V-240V
Product Overview
This APC Smart-UPS is designed for IT managers or network administrators to maintain business uptime, data transfer and continuity during prolonged power outages. The 3kVA line interactive 2U rack/tower UPS provides pure sine wave power to support critical electronics during power disruptions. The SMX comes with IEC 320 C20 input (includes BS1363A, IEC 320 C20 and Schuko CEE 7/EU1-16P power cords), 8x IEC 320 C13 and 1x IEC 320 C19 outlets. The UPS has a SmartSlot for optional Network Management Card that enables graceful shutdown of physical servers, virtual machines & HCI Clusters via PowerChute Network Shutdown. This uninterrupted power supply can connect to EcoStruxure IT or third-party centralized management platforms. The SMX UPS has a 3-year warranty, and the built-in lead-acid battery has a 2-year warranty. This is compatible with dedicated user-replaceable battery, and the APC replacement battery cartridge helps restore UPS performance to the original specifications. The Smart-UPS comes with a pair of tower-mounting stabilizing feet and rack-mounting brackets. The 3 switchable outlet groups allow more granular management of the power supplied to your devices. The Emergency Power Off feature enables the UPS to remotely shutdown during emergencies.
General Information
- Manufacturer: Schneider Electric SA
- Manufacturer Part Number: SMX3000RMHV2U
- Brand Name: APC by Schneider Electric
- Product Line: Smart-UPS
- Product Series: SMX
- Product Model: SMX3000RMHV2U
- Product Name: Smart-UPS 3000 VA Tower/Rack Mountable UPS
- Product Type: Line-interactive UPS
Technical Information
- Plug/Connector Type:
- British BS1363A
- IEC 320-C20
- Receptacle Type: Schuko CEE 7/EU1-16P
- Receptacle Detail:
- 1 x IEC 320-C19
- 2 x IEC Jumper
- 8 x IEC 320-C13
- Number of Battery & Surge Outlets: 11
- Cord Length: 6 ft
- Transfer Time: 4 ms
Power Description
- Load Capacity (VA): 3000 VA
- Load Capacity (Watt): 2700 W
- Input Voltage:
- 208 V AC
- 230 V AC
- Output Voltage:
- 208 V AC
- 230 V AC
- Waveform Type: Sine Wave
- Surge Energy Rating: 645 J
Interfaces/Ports
- Serial Port: Yes
- USB: Yes
Battery Information
- Battery Characteristics: Maintenance-free, Sealed, Spill-proof
- Battery Chemistry: Lead Acid
- Backup/Run Time (Full Load): 6 Minute
- Backup/Run Time (Half Load): 18 Minute
- Hot Swappable: Yes
- Typical Battery Recharge Time: 3 Hour
Physical Characteristics
- Product Color: Black
- Height: 3.3"
- Width: 17"
- Depth: 26.3"
- Rack Height: 2U
- Form Factor: Rack-mountable
- Weight (Approximate): 82.28 lb
Miscellaneous
- Package Contents:
- Smart-UPS 3000 VA Tower/Rack Mountable UPS
- CD with software
- Documentation CD
- Rack mounting brackets
- Smart UPS signalling RS-232 cable
- USB cable
- User manual
- Software Included: Powerchute Serial Edition
- Country of Origin: Philippines
- Environmentally Friendly: Yes
- Environmental Compliance: Restriction of Hazardous Substances (RoHS)
Warranty
- Limited Warranty: 3 Year
- Additional Warranty Information: Battery: 24 month(s)|UPS: 36 month(s)
